Delta R2-EC 004 Series User Manual

Object Dictionary R2-ECx004 User Manual
5-24
5
5.6.5 DO Filter Mask (6208h)
This object sets the DO Filter Mask for R2-EC0004 and R2-EC2004 (8 output channels as a
set). For example, when the value of the sub-index is 00000000, it means the Filter Mask of the
output channel set is disabled, and the value of the output channel set remains the same. When
the value of the sub-index is 11111111, the value of the output channel set is the value set in
OD 6200h.
R2-EC0004
Index
Sub-
index
Name
Data
type
Access
PDO
mapping
Value
6208h
0
DO Filter Mask
USINT
RO
NO
2
1
Port 1 DO
CH0 - 7 Filter Mask
USINT
RW
NO
0 to 255
Default: 255
2
Port 1 DO
CH8 - 15 Filter Mask
USINT
RW
NO
0 to 255
Default: 255
R2-EC2004
Index
Sub-
index
Name
Data
type
Access
PDO
mapping
Value
6208h
0
DO Filter Mask
USINT
RO
NO
4
1
Port 0 DO
CH0 - 7 Filter Mask
USINT
RW
NO
0 to 255
Default: 255
2
Port 0 DO
CH8 - 15 Filter Mask
USINT
RW
NO
0 to 255
Default: 255
3
Port 1 DO
CH0 - 7 Filter Mask
USINT
RW
NO
0 to 255
Default: 255
4
Port 1 DO
CH8 - 15 Filter Mask
USINT
RW
NO
0 to 255
Default: 255
