Delta R2-EC 004 Series User Manual

R2-ECx004 User Manual Object Dictionary
5-23
5
5.6.4 DO Error Mode Setting Value (6207h)
This object sets the DO Error Mode Setting Value for R2-EC0004 and R2-EC2004 (8 output
channels as a set).
R2-EC0004
Index
Sub-
index
Name
Data
type
Access
PDO
mapping
Value
6207h
0
DO Error Mode Setting
Value
USINT
RO
NO
2
1
Port 1 DO CH0 - 7
Error Mode Setting Value
USINT
RW
NO
0 to 255
Default: 0
2
Port 1 DO CH8 - 15
Error Mode Setting Value
USINT
RW
NO
0 to 255
Default: 0
R2-EC2004
Index
Sub-
index
Name
Data
type
Access
PDO
mapping
Value
6207h
0
DO Error Mode Setting
Value
USINT
RO
NO
4
1
Port 0 DO CH0 - 7
Error Mode Setting Value
USINT
RW
NO
0 to 255
Default: 0
2
Port 0 DO CH8 - 15
Error Mode Setting Value
USINT
RW
NO
0 to 255
Default: 0
3
Port 1 DO CH0 - 7
Error Mode Setting Value
USINT
RW
NO
0 to 255
Default: 0
4
Port 1 DO CH8 - 15
Error Mode Setting Value
USINT
RW
NO
0 to 255
Default: 0
