5 Installation
Installation and commissioning must only be carried out by qualied electrical experts!
The prescribed safety regulations, the technical interface conditions (TAB 2000), as well as VDE
specications, are to be complied with.
In order to be able to carry out an energy measurement, a meter must be attached between the
grid feed-in point and the solar inverter (in accordance with the VDEW directive concerning „In-plant
generation systems on the low-voltage mains grid“).
By means of the integrated anti-islanding protection, the function of the prescribed section switch is
fullled in accordance with the VDEW directive.
Caution: The secondary short-circuit current rating is increased at the transfer connection point to
the public electricity supply system by the nominal current of the connected solar inverter.
6 Installation of equipment
6.1 Installation location
• Install the device on a non-inammable support base.
• Avoid installation on resonating bodies (light construction walls etc.).
• Installation is possible both indoors and protected outdoor area.
• An increased ambient temperature can reduce the efciency of the PV system.
• Noise generation possible (avoid installation in the residential area).
• Ensure legibility of the LEDs and the display (read-off angle / installation height).
Although the unit is tted with UV-resistant components, direct exposure to sunlight should be
avoided.
Despite having an IP65 enclosure and being certied in accordance with soiling category III, the
unit must not be allowed to become too heavily soiled.
Heavy soiling can impair the unit’s performance.
6.2 Minimum requirements
• Free convection around the solar inverter must not be impaired.
• For air circulation allow a clearance of approx. 10 cm to the side and approx. 50 cm above and
below the unit.
• The grid impedance at the supply terminal is to be considered (cable length, cable cross-
section).
• The prescribed installation position is to be adhered to (vertical).
• Unused DC connectors (Tyco) and interfaces must be shut through sealing plugs to ensure pro-
tection class IP65 for the whole system (inverter & cables).
