6.9 Electrical connection and operational start-up
The solar inverter is delivered in an operable status.
The electrical connection is implemented on this solar inverter using the connector contacts which
are attached to the casing. In no case must the device be opened!
Power
Controller
Anti-
islanding
protection
Communi-
cation
Operating- and System Control
MPP-
Tracker
-
-
Booster
-
-
Isolation
DC-Bus
-
~
Solar Inverter
DC
DC
DC
DC
String A
String B
String C
String D
AC
Public
mains
