Delta SoLiViA 3.3

30 Operation and installation manual SOLIVIA 3.3 EU G3
Please follow the instructions above before contacting your service technician!
LED STATUS
DISPLAY
MESSAGE
CAUSE ELIMINATION
green: <ashes>
red: <off>
yellow: <off>
PV voltage too
low
PV generator voltage bet-
ween 100 V and 150 V.
- Insufcient insolation.
- Check the PV cell voltage via the
display in the N menu.
green: <ashes>
red: <off>
yellow: <off>
Synchronize
to AC
Check grid voltage and
grid frequency for grid
input mode.
- Normal function before input mode.
green: <on>
red: <off>
yellow: <ashes>
Varistor
warning
Internal varistor at the DC
input is defective.
- Although you can, in theory, carry on
using the solar inverter, the varistors
should be replaced at the earliest oppor
tunity. This will involve returning the
device.
9 Technical data
* The maximum AC power value indicates the power an inverter might be able to deliver. However, such a maximum AC
power may not necessarily be achieved.
** AC voltage and frequency range will be programmed according to the individual country requirements.
INPUT (DC)
Max. recommended PV
power
4000 W
P
Nominal power 3630 W
Voltage range 125 ... 540 V
MPP range 150 ... 450 V
Full power MPP range 150 ... 450 V
Nominal current 13.3 A
Max. current 24.0 A
Stand-by power < 0.2 W
OUTPUT (AC)
Max. power * 3485 W
Nominal power
3300 W
Voltage range ** 184 ... 264 V
Nominal current 14.4 A
Max. current 17.0 A
Nominal frequency 50 Hz
Frequency range ** 47.0 ... 52.0 Hz
Power factor > 0.99 @ nominal power
Total harmonic
distortion (THD)
< 3 % @ nominal power
MECHANICAL DESIGN
Size (L x W x D) 410 x 410 x 180 mm
Weight 21.5 kg
Cooling Convection
AC connector Wieland RST25i3S
DC connector pairs 3 Tyco Solarlok
Communication
interfaces
2 Harting RJ45 / RS485
DC disconnector Integrated
Display LCD; 3 LEDs
STANDARDS / DIRECTIVES
Protection degree IP65
Safety class 1
Configurable trip
parameters
Yes
Insulation monitoring Yes
Overload behavior
Current limitation;
power limitation
Safety
EN60950-1; EN50178;
IEC62103; IEC62109-1 / -2
Anti-islanding
protection
DIN VDE 0126-1-1; RD 1663;
RD 661; ENEL G.L. 2010; UTE
15712-1; Synergrid C10/11;
EN 50438; G83/1-1
EMC
EN61000-6-2; EN61000-6-3;
EN61000-3-2; EN61000-3-3
