Delta VFD-B Series User Manual

Chapter 5 Parameters|VFD-B-P Series
Revision April 2009, SW V1.00 5-3
Parameter Explanation Settings
Factory
Setting
Customer
00-10 Reserved
Group 1 Basic Parameters
Parameter Explanation Settings
Factory
Setting
Customer
01-00
Maximum Output
Frequency (Fmax)
50.00 to 400.00 Hz 60.00
01-01
Maximum Voltage
Frequency (Fbase)
0.10 to 400.00 Hz 60.00
01-02
Maximum Output
Voltage (Vmax)
460V series: 0.1V to 510.0V 440.0
01-03
Mid-Point Frequency
(Fmid)
0.10 to 400.00 Hz 0.50
01-04
Mid-Point Voltage
(Vmid)
460V series: 0.1V to 510.0V 3.4
01-05
Minimum Output
Frequency (Fmin)
0.10 to 400.00 Hz 0.50
01-06
Minimum Output
Voltage (Vmin)
460V series: 0.1V to 510.0V 3.4
01-07
Output Frequency
Upper Limit
1 to 120%
100
01-08
Output Frequency
Lower Limit
0 to100 %
0
01-09 Accel Time 1 0.01 to 3600.0 sec 10.0
01-10 Decel Time 1 0.01 to 3600.0 sec 10.0
01-11 Accel Time 2 0.01 to 3600.0 sec 10.0
01-12 Decel Time 2 0.01 to 3600.0 sec 10.0
01-09 ~ 01-12: Factory setting for models of 30hp (22kW) and above is 60sec.
01-13 Jog Acceleration
Time
0.1 to 3600.0 sec
1.0
01-14 Jog Frequency 0.10 Hz to 400.00 Hz 6.00
00: Linear Accel/Decel
01: Auto Accel, Linear Decel
02: Linear Accel, Auto Decel
03: Auto Accel/Decel (Set by load)
01-15
Auto acceleration /
deceleration (refer to
Accel/Decel time
setting)
04: Auto Accel/Decel (set by Accel/Decel
Time setting)
00
01-16
Acceleration S-
Curve
00 to 07 00
01-17
Deceleration S-
Curve
00 to 07 00
01-18 Accel Time 3 0.01 to 3600.0 sec 10.0
01-19 Decel Time 3 0.01 to 3600.0 sec 10.0
01-20 Accel Time 4 0.01 to 3600.0 sec 10.0
01-21 Decel Time 4 0.01 to 3600.0 sec 10.0
01-18 ~ 01-21: Factory setting for models of 30hp (22kW) and above is 60sec.
01-22 Jog Deceleration
Time
0.1 to 3600.0 sec
1.0
01-23 Accel/Decel Time 00: Unit: 1 sec 01

Delta VFD-B Series Specifications

General

Series	VFD-B
Cooling Method	Fan cooling
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Control Mode	V/F control, Sensorless Vector Control
Communication	RS-485
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH (non-condensing)
Altitude	1000m (Derating required above 1000m)
