Chapter 5 Parameters|VFD-B-P Series
5-2 Revision April 2009, SW V1.00
5.1 Summary of Parameter Settings
: The parameter can be set during operation.
Group 0 User Parameters
Parameter Explanation Settings
Factory
Setting
Customer
00-00 Identity Code of
the AC motor drive
Read-only ##
00-01 Rated Current
Display of the AC
motor drive
Read-only #.#
08: Keypad lock
09: All parameters are reset to factory settings
(50Hz, 380V)
00-02 Parameter Reset
10: All parameters are reset to factory settings
(60Hz, 440V)
00
00: Display the frequency command value (LED
F)
01: Display the actual output frequency (LED H)
02: Display the content of user-defined unit
(LED U)
03: Multifunction display, see Pr.00-04
00-03
Start-up Display
Selection
04: FWD/REV command
00
00: Display output current (A)
01: Display counter value (C)
02: Display process operation (1.tt)
03: Display DC-BUS voltage (
u
)
04: Display output voltage (E)
05: Output power factor angle (n)
06: Display output power (P)
07: Display actual motor speed (HU)
08: Display the estimated value of torque as it
relates to current (t)
09: Display PG numbers/10ms (G)
10: Display analog feedback signal value (b)(%)
11: Display AVI (U1.) (%)
12: Display ACI (U2.) (%)
13: Display AUI (U3.) (%)
00-04
Content of Multi
Function Display
14: Display the temperature of heat sink (°C)
00
00-05
User-Defined
Coefficient K
0.01 to 160.00 1.00
00-06 Software Version Read-only #.##
00-07 Password Input 00 to 65535 00
00-08 Password Set 00 to 65535 00
00: V/f Control
01: V/f + PG Control
02: Vector Control
00-09 Control Method
03: Vector + PG Control
00
