Delta VFD-B Series User Manual

Chapter 2 Installation and Wiring|VFD-B-P Series
2-10 Revision April 2009, SW V1.00
2.3 Dimensions
(Dimensions are in millimeter and [inch])
VFD022B43P-A
148.0 [5.83]
215.0 [8.46]
215.0 [8.46]
M
5
.
0
(
4
X
)
201.0 [7.91]
184.6 [7.27]
117.8 [4.64]
134.0 [5.28]
65.0 [2.56]
160.0 [6.30]
5.5[0.22]
R
2.
7
5[
0
.
11
]
2
2
.
0
[
0
.
8
7
]
2
8
.
0
[
1
.
1
0
]
(
2
X)

Delta VFD-B Series Specifications

General

Series	VFD-B
Cooling Method	Fan cooling
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Control Mode	V/F control, Sensorless Vector Control
Communication	RS-485
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH (non-condensing)
Altitude	1000m (Derating required above 1000m)
