Chapter 5 Parameters|VFD-B-P Series
Revision April 2009, SW V1.00 5-23
5.3 Description of Parameter Settings
Group 0: User Parameters : This parameter can be set during operation.
00 - 00 Identity Code of the AC motor drive
Settings Read Only Factory setting: ##
00 - 01 Rated Current Display of the AC motor drive
Settings Read Only Factory setting: #.#
Pr. 00-00 displays the identity code of the AC motor drive. The capacity, rated current, rated
voltage and the max. carrier frequency relate to the identity code. Users can use the following
table to check how the rated current, rated voltage and max. carrier frequency of the AC motor
drive correspond to the identity code.
Pr.00-01 displays the rated current of the AC motor drive. By reading this parameter the user
can check if the AC motor drive is correct.
460V Series
kW 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45
HP 3.0 5.0 7.5 10 15 20 25 30 40 50 60
Pr.00-00 09 11 13 15 17 19 21 23 25 27 29
Rated Output
Current (A)
4.2 5.5 13 18 24 32 38 45 60 73 91
V/f
Control
15kHz 9kHz 6kHz
Max.
Carrier
Frequency
Vector
Control
15kHz 9kHz
00 - 02 Parameter Reset
Factory Setting: 00
Settings 08 Keypad Lock
09 All parameters are reset to factory settings (50Hz, 380V)
10 All parameters are reset to factory settings (60Hz, 440V)
This parameter allows the user to reset all parameters to the factory settings except the fault
records (Pr.06-08 ~ Pr.06-11).
When Pr.00-02=08, the VFD-PU01 keypad is locked. To unlock the keypad, set Pr.00-02=00.
00 - 03
Start-up Display Selection
Factory Setting: 00
Settings 00 Display the frequency command value. (LED F)
