Chapter 5 Parameters|VFD-B-P Series
5-6 Revision April 2009, SW V1.00
Parameter Explanation Settings
Factory
Setting
Customer
00: Digital keypad (PU01)
01: External terminals. Keypad STOP/RESET
enabled.
02: External terminals. Keypad STOP/RESET
disabled.
03: RS-485 serial communication (RJ-11).
Keypad STOP/RESET enabled.
02-14
Source of Second
Operation Command
04: RS-485 serial communication (RJ-11).
Keypad STOP/RESET disabled.
00
02-15
Keypad Frequency
Command
0.00 ~ 400.00Hz 60.00
Group 3 Output Function Parameters
Parameter Explanation Settings
Factory
Setting
Customer
00: No function
01: AC drive operational
02: Master frequency attained
03-00
Multi-Function
Output Relay (RA1,
RB1, RC1)
03: Zero speed
08
04: Over torque detection
05: Base-Block (B.B.) indication
06: Low-voltage indication
03-01
Multi-Function
Output Terminal
MO1
07: Operation mode indication
01
08: Fault indication
09: Desired frequency attained 1
10: PLC program running
03-02
Multi-Function
Output Terminal
MO2
11: PLC program step completed
02
12: PLC program completed
13: PLC program operation paused
14: Terminal count value attained
15: Preliminary count value attained
16: Auxiliary motor No.1
17: Auxiliary motor No.2
18: Auxiliary motor No.3
19: Heat sink overheat warning
20: AC motor drive ready
21: Emergency stop indication
22: Desired frequency attained 2
23: Software brake signal
24: Zero speed output signal
25: Under-current detection
26: Operation indication (H>=Fmin)
27: Feedback signal error
28: User-defined low-voltage detection
03-03
Multi-Function
Output Terminal
MO3
29: Brake control (Desired frequency attained
3)
20
To Next Page
