Delta VFD-B Series User Manual

Chapter 5 Parameters|VFD-B-P Series
5-8 Revision April 2009, SW V1.00
Parameter Explanation Settings
Factory
Setting
Customer
07: Accel/Decel time selection command 1
08: Accel/Decel time selection command 2
09: External base block (N.O.) 03
10: External base block (N.C.)
04-06 Multi-Function Input
Terminal 3 (MI3)
11: Up: Increment master frequency
12: Down: Decrement master frequency
04
13: Counter reset
14: Run PLC program
04-07 Multi-Function Input
Terminal 4 (MI4)
15: Pause PLC program
16: Auxiliary motor No.1 output disable
05
17: Auxiliary motor No.2 output disable
18: Auxiliary motor No.3 output disable
04-08 Multi-Function Input
Terminal 5 (MI5)
19: Emergency stop (N.O.)
20: Emergency stop (N.C.) 06
21: Master frequency selection AVI/ACI
22: Master frequency selection AVI/AUI
23: Operation command selection
(keypad/external terminals)
24: Auto accel/decel mode disable
25: Forced stop (N.C.)
26: Forced stop (N.O.)
27: Parameter lock enable (N.O.)
28: PID function disabled
29: Jog FWD/REV command
30: External reset (N.C.)
31: Source of second frequency command
enabled
32: Source of second operation command
enabled
33: One shot PLC
34: Proximity sensor input for simple Index
function
35: Output shutoff stop (NO)
04-09 Multi-Function Input
Terminal 6 (MI6)
36: Output shutoff stop (NC)
04-10
Digital Terminal
Input Debouncing
Time
1 to 20 (*2ms) 01
04-11
ACI Analog Input
Bias
0.00~200.00 % 0.00
00: Positive bias
04-12 ACI Bias Polarity
01: Negative bias
00
04-13 ACI Input Gain 01 to 200 % 100

Delta VFD-B Series Specifications

General

Series	VFD-B
Cooling Method	Fan cooling
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Control Mode	V/F control, Sensorless Vector Control
Communication	RS-485
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH (non-condensing)
Altitude	1000m (Derating required above 1000m)
