Delta VFD-B Series User Manual

Chapter 5 Parameters|VFD-B-P Series
5-10 Revision April 2009, SW V1.00
Parameter Explanation Settings
Factory
Setting
Customer
05-07 8
th
Step Speed
Frequency
0.00 to 400.00 Hz 0.00
05-08 9
th
Step Speed
Frequency
0.00 to 400.00 Hz 0.00
05-09 10
th
Step Speed
Frequency
0.00 to 400.00 Hz 0.00
05-10 11
th
Step Speed
Frequency
0.00 to 400.00 Hz 0.00
05-11 12
th
Step Speed
Frequency
0.00 to 400.00 Hz 0.00
05-12 13
th
Step Speed
Frequency
0.00 to 400.00 Hz 0.00
05-13 14
th
Step Speed
Frequency
0.00 to 400.00 Hz 0.00
05-14 15
th
Step Speed
Frequency
0.00 to 400.00 Hz 0.00
00: Disable PLC operation
01: Execute one program cycle
02: Continuously execute program cycles
03: Execute one program cycle step by step
05-15 PLC Mode
04: Continuously execute program cycles
step by step
00
05-16 PLC Forward/
Reverse Motion
00 to 32767 (00: FWD, 01: REV) 00
05-17 Time Duration of 1st
Step Speed
00 to 65500 sec or 00 to 6550.0 sec 00
05-18 Time Duration of 2nd
Step Speed
00 to 65500 sec or 00 to 6550.0 sec 00
05-19 Time Duration of 3rd
Step Speed
00 to 65500 sec or 00 to 6550.0 sec 00
05-20 Time Duration of 4th
Step Speed
00 to 65500 sec or 00 to 6550.0 sec 00
05-21 Time Duration of 5th
Step Speed
00 to 65500 sec or 00 to 6550.0 sec 00
05-22 Time Duration of 6th
Step Speed
00 to 65500 sec or 00 to 6550.0 sec 00
05-23 Time Duration of 7th
Step Speed
00 to 65500 sec or 00 to 6550.0 sec 00
05-24 Time Duration of 8th
Step Speed
00 to 65500 sec or 00 to 6550.0 sec 00
05-25 Time Duration of 9th
Step Speed
00 to 65500 sec or 00 to 6550.0 sec 00
05-26 Time Duration of
10th Step Speed
00 to 65500 sec or 00 to 6550.0 sec 00
05-27 Time Duration of
11th Step Speed
00 to 65500 sec or 00 to 6550.0 sec 00
05-28 Time Duration of
12th Step Speed
00 to 65500 sec or 00 to 6550.0 sec 00
05-29 Time Duration of
13th Step Speed
00 to 65500 sec or 00 to 6550.0 sec 00

Delta VFD-B Series Specifications

General

Series	VFD-B
Cooling Method	Fan cooling
Overload Capacity	150% for 60 seconds
Braking Unit	Built-in
Control Mode	V/F control, Sensorless Vector Control
Communication	RS-485
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overload, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	90% RH (non-condensing)
Altitude	1000m (Derating required above 1000m)
