Chapter 1 IntroductionVFD-EL-W
7
Remove the control board cover
As shown in Step 1 below, gently press the control
board cover. Then, as shown in Step 2, pull it down
slowly to remove it.
Step 1
Step2
Remove cooling fan:
To remove the cooling fan of Frame B, gently release the clips
on both sides of the cooling fan.
