Page #44 background imageLoading...
Page #44 background image
Chapter 4 ParametersVFD-EL-W
39
4-1 Summary of Parameter Settings
NOTE: Parameters/ options marked in Gray are applied only for V1.00_5.5 kW models.
00 User Parameters
You can set this parameter during operation.
Pr.
Parameter Name
Setting Range
Default
00.00
AC Motor Drive Identity
Code
0: 230V, 0.25 HP
2: 230V, 0.5 HP
3: 460V, 0.5 HP
4: 230V, 1 HP
5: 460V, 1 HP
6: 230V, 2 HP
7: 460V, 2 HP
8: 230V, 3 HP
9: 460V, 3 HP
11: 460V, 5.5 HP
13: 460V, 7.5 HP
Read
only
00.01
AC Motor Drive Rated
Current Display
Display by models
Read
only
00.02
Parameter Reset
0: Parameter can be read/written
1: All parameters are read only
7: Keypad and frequency setting knob locked
8: Keypad lock
9: Reset all parameters to defaults (50 Hz,
230V/400V or 220V/380V depends on Pr.00.12)
10: Reset all parameters to defaults (60 Hz,
220V/440V)
0
00.03
Start-up Display
0: F (frequency command)
1: H (output frequency)
2: A (output current)
3: U (user-defined, see Pr.00.04)
4: FWD/REV command
0
00.04
Content of Multi-function
Display (User-Defined)
0: Display the content of user-defined unit
1: Display counter value (c)
2: Display the status of multi-function input terminal
(d)
3: Display the drive's DC bus voltage (u)
4: Display the drive’s output voltage (E)
5: Display PID analog feedback signal (b)
6: Display the drive's power factor angle (n)
7: Display the drive’s output power (P)
0
