Delta VFD-EL-W Series User Manual

Chapter 4 Parameters｜VFD-EL-W
128
}
}
}
return reg_crc; // return register CRC
Address list
Content
Parameter
address
Function
AC motor drive
parameters
GGnnH
GG is the parameter group, nn is the parameter number. For
example, the address of Pr.04-10 is 0401H.
Command write only
2000H
bit0–1
00B: No function
01B: Stop
10B: Run
11B: JOG + RUN
bit2–3
Reserved
bit4–5
00B: No function
01B: FWD
10B: Direction reverse
11B: Change direction
bit6–7
00B: 1st step accel./decel.
01B: 2nd step accel./decel.
bit8–15
Reserved
2001H
Frequency command
2002H
bit0
1: EF ON
bit1
1: Reset command
bit2
1: Base Block (B.B) ON
bit3–4
bit6–15
Reserved
Enable Fire Mode
bit5
00B: No function
01B: Start Fire Mode (without RUN command)
Status monitor read
only
2100H
Error code
0: No fault record
1: Over-current (oc)
2: Over-voltage (ov)
3: IGBT overheat (OH1)
4: Reserved
5: Drive Over load (oL)
6: Motor over load (oL1)
7: Over-torque (oL2)
8: External fault (EF)
9: Over-current during acceleration (ocA)
10: Over-current during deceleration (ocd)
11: Over-current at constant speed (ocn)
12: Reserved
13: Low voltage (Lv)
14: Input phase loss (PHL)
