Chapter 4 Parameters｜VFD-EL-W
129
Content
Parameter
address
Function
15: Reserved
16: Auto-acceleration / auto-deceleration failure (cFA)
17: Software and parameter password protection (codE)
18: CPU write error (cF1.0)
19: CPU read error (cF2.0)
20: CC, OC hardware protection error (HPF1)
21: OV hardware protection error (HPF2)
22: Reserved
23: OC hardware protection error (HPF4)
24: U-phase hardware error (cF3.0)
25: V-phase hardware error (cF3.1)
26: W-phase hardware error (cF3.2)
27: DC bus hardware error (cF3.3)
28: OH1 hardware error (cF3.4)
29: Reserved
30: Reserved
31: Reserved
32: Reserved
33: Reserved
34: Reserved
35: Reserved
36: Reserved
37: OPHL
2101H
bit 0–1
LED status of digital keypad
00B: RUN LED is OFF, STOP LED is ON (the drive
stops)
01B: RUN LED flashes, STOP LED is ON (when drive
decelerates to stop)
10B: RUN LED is ON, STOP LED flashes (the drive is
standby)
11B: RUN LED is ON, STOP LED is off (the drive runs)
bit 2
1: JOG command
bit 3–4
00B: FWD light is ON, REV light is OFF (the drive runs
in a forward direction)
01B: FWD light is ON, REV light flashes (when the
drive changes the running direction from REV to
FWD)
10B: FWD light flashes, REV light is ON (when the
drive changes the running direction from FWD to
REV)
11B: FWD light is OFF, REV light is ON (the drive runs
in a reverse direction)
bit 5–7
Reserved
bit 8
1: Master frequency controlled by the communication
interface
bit 9
1: Master Frequency command controlled by analog
signal input
