Chapter 4 Parameters｜VFD-EL-W
151
Pr.
Function
Setting Range
Default
User's
Master
User’s
Slave
Note
01.00
Max. Operation
Frequency
50.00–400.0 Hz
60.00
60.00
60.00
Set the parameters
according to the
specifications of
pumps.
01.01
Motor Rated
Frequency
0.10–400.0 Hz
60.00
60.00
60.00
01.02
Motor Rated
Voltage
230V models: 0.1–255.0 V
220.0
220.0
220.0
460V models: 0.1–510.0 V
400.0
400.0
400.0

01.09
Acceleration Time
1
0.1–600.0 sec./ 0.01–600.00 sec.
10.0
0.5
0.5
Adjust the parameter
according to
customer’s
applications

01.10
Deceleration Time
1
0.1–600.0 sec./ 0.01–600.00 sec.
10.0
5.0
5.0

01.12
Deceleration Time
2
0.1–600.0 sec./ 0.01–600.00 sec.
10.0
3.0
3.0
The time for the drive
decelerating to stop
when the pressure
reaches the setting
value.

02.00
First Master
Frequency
Command Source
0: Digital keypad
1: External terminal AVI analog
signal DC 0–10V
2: External terminal ACI analog
signal DC 4–20 mA
3: RS-485 communication input
4: Digital keypad potentiometer
knob
0
2
2
Adjust the parameter
according to
customer’s
applications

02.01
Operation
Command Source
0: Digital keypad
1: External terminals, STOP key is
valid
2: External terminals, STOP key is
invalid
3: RS-485 communication, STOP
key is valid
4: RS-485 communication, STOP
key is invalid
0
0
0
Adjust the parameter
according to
customer’s
applications
10.35
Multi-Pump
Operation Mode
0: Disable
1: Fixed time circulation
(alternative operation)
2: Fixed quantity control (multi-
pump operating at constant
pressure)
0
1
1
10.36
Multi-Pump ID
0: Disable multi-pump function
1: Master
2–4: Slave
0
1
2
10.37
Multi-Pump Fixed
Time Circulation
Period
1–65535 min.
60
1
1
10.42
Pump’s Frequency
at Time-Out
(Disconnection)
0.0–Fmax
0.00
60
60
10.43
Pump Fault
Treatment
bit 0: When the
operating pump is
failed, whether it
switches to an
alternative pump
or not
0: Stop all pump action
1: Switch to an alternative pump
1
1
1
000 = 0
001 = 1
010 = 2
011 = 3
100 = 4
101 = 5
110 = 6
111 = 7
bit 1: During the
operation, stop or
standby after
resetting from
error
0: Standby after resetting
1: Stop after resetting
bit2 Whether the
system can run or
not when the
0: 0: The system cannot activate
1: The system selects another
pump to operate
