To prevent lightning strike and electric shock, the metal grounding wire of electrical
equipment should be thick and short, and connected to the dedicated grounding terminal of
the inverter system.
You can install multiple VFD-EL-W units in one location. All the units should be grounded
directly to a common ground terminal, as shown in the figure below. Ensure that there are
no ground loops.
