Chapter 3 Keypad and Start-up VFD-EL-W
33
3-1-3 Keypad Operation Process
To shift data
Setting direction
Setting Mode
Setting parameters
Success to
set parameter.
Input data error
NOTE：
In the parameter setting mode, you can press
to return the selecting mode.
(When operation source is digital keypad)
S TAR T
GO START
MODE MODE MODE MODE MODE
NOTE:
In the selection mode, press
to set the parameters. MODE
or
ENTER ENTER ENTER
MODE
or
MODE MODE MODE MODE
3-1-4 Reference Table for the Seven-segment LED Display of the Digital Keypad
Digit
0
1
2
3
4
5
6
7
8
9
Led Display
English Alphabet
A
b
Cc
d
E
F
G
Hh
Ii
Jj
Led Display
English Alphabet
K
L
n
Oo
P
q
r
S
Tt
U
Led Display
English Alphabet
v
Y
Z
Led Display
