Delta VFD-EL-W Series User Manual

Chapter 4 Parameters｜VFD-EL-W
44
Pr.
Parameter Name
Setting Range
Default
3: Operates at the frequency of Pr.02.11
02.07
External Terminal Up/Down
Key Mode Selection
0: By Up/ Down key
1: By acceleration/ deceleration time
2: By constant speed (Pr.02.08)
3: By pulse (Pr.02.08)
0
02.08
External Terminal Speed of
the Up/ Down Key
0.01–10.00 Hz/2ms
0.01

02.09
Second Master Frequency
Command Source
0: Digital keypad input or external terminals (up/
down function)
1: External terminal AVI analog input DC 0–10 V
2: External terminal ACI analog signal DC 4–20 mA
3: RS-485 communication input
4: Digital keypad potentiometer knob
0

02.10
First / Second Master
Frequency Command
Combination
0: First master frequency command only
1: First master frequency command + second
master frequency command
2: First master frequency command - second master
frequency command
0

02.11
Keypad Frequency
Command
0.00–400.0 Hz
60.00

02.12
Communication Frequency
Command
0.00–400.0 Hz
60.00
02.13
Frequency Command
Saving Mode
0: Save the frequency before power-off
1: Only save the keypad frequency command before
power-off
2: Only save the communication frequency
command before power-off
0
02.14
Initial Frequency Command
Mode at Stop
0: Use current Frequency command
1: Use zero Frequency command
2: Refer to Pr.02.15 to set up
0
02.15
Initial Frequency Command
Setting at Stop
0.00–400.0 Hz
60.00
02.16
Frequency Command
Source Display
1: bit0 = 1: First frequency command source
(Pr.02.00)
2: bit1 = 1: Second frequency command source
(Pr.02.09)
4: bit2 = 1: Set by external MI terminal
Read
only
02.17
Operation Command
Source Display
1: bit0 = 1: Digital keypad
2: bit1 = 1: RS-485
4: bit2 = 1: External terminals
Read
only
