Delta VFD-EL-W Series User Manual

Chapter 4 Parameters｜VFD-EL-W
49
Pr.
Parameter Name
Setting Range
Default
22: Second frequency command source
23: Simple positioning FWD stop limit
24: Simple positioning REV stop limit
25: Multi-pump manual/ auto switch
29: Prohibit write EEPROM
04.09
Multi-Function Input Contact
Selection (N.O./ N.C.)
0–63
0
04.10
Digital Terminal Input Response
Time
1–20 (*2ms)
1

04.11
Minimum AVI Input Voltage
0.0–10.0 V
0.0

04.12
Minimum AVI Input Frequency
0.0–100.0% Fmax
0.0

04.13
Maximum AVI Input Voltage
0.0–10.0 V
10.0

04.14
Maximum AVI Input Frequency
0.0–100.0% Fmax
100.0

04.15
Minimum ACI Input Current
0.0–20.0 mA
4.0

04.16
Minimum ACI Input Frequency
0.0–100.0% Fmax
0.0

04.17
Maximum ACI Input Current
0.0–20.0 mA
20.0

04.18
Maximum ACI Input Frequency
0.0–100.0% Fmax
100.0
04.19
MI Terminal Control Mode Selection
0: Mode 1, single-wire start/ stop
1: Mode 2, two-wire/ three-wire start/ stop
0
04.20
–
04.25
Reserved
04.26
Display the Status of Multi-function
Input Terminal
Refer to Description of Parameter Settings
Read
only

04.27
Internal/ External Multi-Function
Input Terminal Selection
0–63
0

04.28
Internal Multi-Function Input
Terminal Setting
0–63
0
