Delta VFD-EL-W Series User Manual

Chapter 4 Parameters｜VFD-EL-W
52
Pr.
Parameter Name
Setting Range
Default
06.24
Fault Record 9
8: External fault (EF)
0
06.25
Fault Record 10
9: Over-current during acceleration (ocA)
0
10: Over-current during deceleration (ocd)
11: Over-current at constant speed (ocn)
12: Reserved
13: Reserved
14: Phase loss (PHL)
15: Reserved
16: Auto-acceleration/ auto-deceleration fail (cFA)
17: Software or password protection (codE)
18: Write error (cF1.0)
19: Read error (cF2.0)
20: Protection circuit error (HPF1)
21: Protection circuit error (HPF2)
22: Reserved
23: Protection circuit error (HPF4)
24: U-phase hardware error (cF3.0)
25: V-phase hardware error (cF3.1)
26: W-phase hardware error (cF3.2)
27: DC bus hardware error (cF3.3)
28: OH1 hardware error (cF3.4)
29: Reserved
30: Reserved
31: Reserved
32: Analog feedback signal error (AErr)
33: Reserved
34: Motor overheating (PTC1)
35: PID feedback fault (FbE)
36: PID feedback error (dEv)
37: Output phase loss (OPHL)
38–40: Reserved

06.13
Detection Time for Motor
Phase Loss
0.0: Disabled
0.1–60.0 sec.
0

06.14
Detection Current Level for
Motor Phase Loss
10–100%
30
06.26
Output Frequency Fault 1
(Hz)
0–65535
0
06.27
Output Current Fault 1
0–65535
0
06.28
Output Voltage Fault 1
0–65535
0
06.29
DC bus Voltage Fault 1
0–65535
0
