07 Motor Parameters
 You can set this parameter during operation.
Pr.
Parameter Name
Setting Range
Default

07.00
Motor Rated Current
30–120% FLA
(FLA: drive’s rated current)
100%
FLA

07.01
No-Load Current for Motor
0–99% FLA
40%
FLA

07.02
Auto-Torque Compensation
0.0–10.0
0.0

07.03
Torque Compensation Gain
0.00–10.00
0.00

07.04
Motor Parameter Auto-Tuning
0: Disabled
1: Auto-tuning R1 (motor does not run)
2: Auto-tuning R1 + no-load current (motor
runs)
0
07.05
Motor Resistance R1 (Line to
Line)
0–65535 mΩ
0
07.06
Motor Rated Slip
0.00–20.00 Hz
3.00
07.07
Slip Compensation Limit
0–250%
200
07.08
Torque Compensation Low Pass
Filter Time
0.01–10.00 sec.
0.10
07.09
Slip Compensation Low Pass
Filter Time
0.05–10.00 sec.
0.20
07.10
Accumulated Motor Operation
Time (Minutes)
00–1439 min.
0
07.11
Accumulated Motor Operation
Time (Days)
00–65535 days
0
07.12
Motor PTC Overheating
Protection
0: Disable
1: Enable
0
07.13
Motor PTC Overheating
Protection Input Filter Time
0–9999 (unit: 2ms)
100
07.14
Motor PTC Overheating
Protection Level
0.1–10.0 V
2.4
07.15
Motor PTC Overheating Warning
Level
0.1–10.0 V
1.2
07.16
Motor PTC Overheating Warning
Reset Level Difference
0.1–5.0 V
0.6
07.17
Motor PTC Overheating Action
0: Warn and ramp to stop
1: Warn and coast to stop
2: Warn and continue operation
0
