Chapter 1 IntroductionVFD-EL-W
4
Drive Frames and Appearances
Frame A1
choose NPN/PNP
input terminals
frequency control knob
digital keypad
control board cover
output terminals
grounding terminals
digital keypad
choose ACI/AVI
control treminals
RS485 terminal
(RJ45)
Frame A2
NPN/PNP选择
input terminals
frequency control knob
digital keypad
digital keypad
choose NPN/ PNP
choose ACI/ AVI
control terminals
RS485 terminal
(RJ45)
control board cover
output terminals
grounding terminals
