Chapter 7 Optional AccessoriesC2000 Plus
7-14
7-3 Fuse Specification Chart
 Fuse specifications lower than the table below are allowed.
 For installation in the United States, branch circuit protection must be provided in accordance with the
National Electrical Code (NEC) and any applicable local codes. Use UL classified fuses to fulfill this
requirement.
 For installation in Canada, branch circuit protection must be provided in accordance with Canadian
Electrical Code and any applicable provincial codes. Use UL classified fuses to fulfill this
requirement.
230V Models
Input Current I (A) Line Fuse
Super Heavy
Duty
Heavy Duty I (A) Bussmann P/N
VFD007C23A-21 3.9 6.4 15 JJN-15 / JJS-15
VFD015C23A-21 6.4 12 25 JJN-25 / JJS-25
VFD022C23A-21 12 16 35 JJN-35 / JJS-35
VFD037C23A-21 16 20 45 JJN-45 / JJS-45
VFD055C23A-21 20 28 60 JJN-60 / JJS-60
VFD075C23A-21 28 36 80 JJN-80 / JJS-80
VFD110C23A-21 36 52 110 JJN-110 / JJS-110
VFD150C23A-21 52 72 150 JJN-150 / JJS-150
VFD185C23A-21 72 83 175 JJN-175 / JJS-175
VFD220C23A-21 83 99 225 JJN-225 / JJS-225
VFD300C23A-00
VFD300C23A-21
99 124 250 JJN-250 / JJS-250
VFD370C23A-00
VFD370C23A-21
124 143 300 JJN-300 / JJS-300
VFD450C23A-00
VFD450C23A-21
143 171 400 JJN-400 / JJS-400
VFD550C23A-00
VFD550C23A-21
171 206 450 JJN-450 / JJS-450
VFD750C23A-00
VFD750C23A-21
206 245 500 JJN-500 / JJS-500
VFD900C23A-00
VFD900C23A-21
245 331 700 JJN-700 / JJS-700
460V Models
Input Current I (A) Line Fuse
Super Heavy
Duty
Heavy Duty I (A) Bussmann P/N
VFD007C43A-21
VFD007C4EA-21
3.5 4.3 10 JJS-10
VFD015C43A-21
VFD015C4EA -21
4.3 5.9 15 JJS-15
VFD022C43A-21
VFD022C4EA-21
5.9 8.7 20 JJS-20
VFD037C43A-21
VFD037C4EA-21
8.7 14 30 JJS-30
VFD040C43A-21
VFD040C4EA-21
14 15.5 35 JJS-35
VFD055C43A-21
VFD055C4EA-21
15.5 17 40 JJS-40
VFD075C43A-21
VFD075C4EA-21
17 20 45 JJS-45
Table 7-15
