Chapter 11 Summary of Parameter SettingsC2000 Plus
11-2
This chapter provides a summary of parameter (Pr.) setting ranges and defaults. You can set, change,
and reset parameters through the digital keypad.
NOTE:
1. : You can set this parameter during operation
2. For more details on parameters, refer to chapter 12 Description of Parameter Settings.
3. The following are abbreviations for different types of motors:
 IM: Induction motor
 PM: Permanent magnet synchronous AC motor
 IPM: Interior permanent magnet synchronous AC motor
 SPM: Surface permanent magnet synchronous AC motor
 SynRM: Synchronous reluctance motor
00 Drive Parameters
Pr. Parameter Name Setting Range
Default
00-00 AC Motor Drive Identity Code
4: 230V, 0.75 kW
5: 460V, 0.75 kW
6: 230V, 1.50 kW
7: 460V, 1.50 kW
8: 230V, 2.20 kW
9: 460V, 2.20 kW
10: 230V, 3.70 kW
11: 460V, 3.70 kW
12: 230V, 5.50 kW
13: 460V, 5.50 kW
14: 230V, 7.50 kW
15: 460V, 7.50 kW
16: 230V, 11.0 kW
17: 460V, 11.0 kW
18: 230V, 15.0 kW
19: 460V, 15.0 kW
20: 230V, 18.5 kW
21: 460V, 18.5 kW
22: 230V, 22.0 kW
23: 460V, 22.0 kW
24: 230V, 30.0 kW
25: 460V, 30.0 kW
26: 230V, 37.0 kW
27: 460V, 37.0 kW
28: 230V, 45.0 kW
29: 460V, 45.0 kW
30: 230V, 55.0 kW
31: 460V, 55.0 kW
32: 230V, 75.0 kW
Read
only
