Chapter 8 Option CardsC2000 Plus
8-16
8-4 EMC-R6AA -- Relay output extension card (6-point N.O. output contact)
Relay Extension
Card
Terminals Descriptions
RA10–RA15
RC10–RC15
Refer to Pr.02-36– Pr.02-41 for multi-function output selection
Resistive load:
3A (N.O.) / 250 V
AC
5A (N.O.) / 30 V
DC
Inductive load (COS 0.4)
1.2A (N.O.) / 250 V
AC
2.0A (N.O.) / 30 V
DC
It is used to output each monitor signal, such as drive is in
operation, frequency attained or overload indication.
8-5 EMC-BPS01 -- +24V power card
External Power
Supply
Terminals Descriptions
24V
GND
Input power: 24 V± 5%
Maximum input current: 0.5 A
NOTE:
Do not connect drive control terminal GND directly to the EMC-
BPS01 input terminal GND.
Function:
When the drive is only powered by EMC-BPS01, the
communication can be assured and support all communication
cards and following functions:
Parameters read and write
Keypad can be displayed
Keypad button can be operated (except RUN)
Analog input is effective
Multi-input (FWD, REV, MI1–MI8) needs external power
supply to operate
Following functions are not supported：
Relay output (including extension card), PG card, PLC function
