78
Under Voltage Protection
IEC 61850
IEC 60617
IEEE-ANSI
-1
PHI_PIUV_1
U<
27-I-1
-2
PHI_PIUV_2
U<<
27-I-2
Under Voltage Protection Function Symbols
The menu consists of nine lines and the menu display is as follows.
Under Voltage Protection Display
Under Voltage Protection Display
