DEMA DPM 400 D - Protection

97
4.3.5.3 32OQ – Directional Reactive Over Power 
The Directional Active Over Power settings are Main Menu> Protection Settings> Power
Protection Settings> Directional Reactive Over Power
Directional Active Over Power is indicated by Q> ve Q>> in IEC 60617; QI_PDOP_1 ve
QI_PDOP_2 in IEC 61850; 32OQ-I-1 ve 32OQ-I-2 in IEEE/ANSI Standards
Directional Reactive Over Power Protection
IEC 61850
IEC 60617
IEEE-ANSI
-1
QI_PDOP_1
Q>
32OQ-I-1
-2
QI_PDOP_2
Q>>
32OQ-I-2
Directional Reactive Over Power Function Symbols
The menu consists of six lines. The menu view is as follows.
Directional Reactive Over Power
4.3.5.3.1 Protection

activated in the active state and disabled in the passive state
