Denlar D1000 - Wiring Diagrams; Electric Contactor Wiring; Gas Solenoid Wiring

The D1000
Installation and
Service
Version 2.1
9
50AMP 250V
NEMA 14-50
L1 208-220 VAC Black Hot
L3 208-220 VAC Red Hot
T1 208-220 VAC Black Hot
T3 208-220 VAC Red Hot
}
}
Not Supplied by DFP
Supplied by DFP
T1
L1
T3
L3
50 AMP 208-240 VAC Single Phase
Supply Line (not supplied by DFP)
110 VAC Coil
Wire Nut
Neutral
Lines
6 Position
Orange
Connector
6 Position
Orange
Connector
6 Position
Grey
Connector
6 Position
Grey
Connector
15 AMP 110-120 VAC
Supply Line
(not supplied by DFP)
15 AMP 110-120 VAC
Supply Line
(not supplied by DFP)
Metal Clad to 110-120 VAC
Power Disconnect (Supplied
by DFP) Black Tape - 14/2
Metal Clad Wire from 110-120 VAC
Supply Line (Red tape)
Metal Clad Wire from 110-120 VAC
Supply Line (Red tape)
Multiconductor
(4 Conductor)
110-120 VAC Gas Solenoid
Green Ground
Wire nut inside power
disconnect box
Green
Green Ground
Green Ground
Green Ground
Black Hot
110-120 VAC 14/2
Black
Hood
Hood
White Neutral
White Neutral
White Neutral
Black Hot 110-120 VAC
Black Hot 110-120 VAC
Black Hot 110-120 VAC
Junction
Box
Junction
Box
Junction Box
Wire Nut
White Neutral
White
Contactor 50A
Supplied
by DFP
Power Disconnect Box
8” x 6” x 4”
Back Support
Mounting Bracket
Back Plate
GND
NEUT
HOT
GND
NEUT
HOT
GND
NEUT
HOT
GND
NEUT
HOT
H
N
H
HH
Metal Clad to 110-120 VAC
Power Disconnect (Sup-
plied by DFP) (Black Tape)
Gas Solenoid
Electric Contactor
