Denlar D1000 - Sample Elevations

The D1000
Installation and
Service
Version 2.1
3
Sample Elevations
Plenum Ready Supply
Cable to Fan
Power Disconnect
Cable
Cabinet
110VAC Supply Cable
Range Hood
7” Ductwork
Fan
Air
Flow
Plenum Ready Supply
Cable to Fan
Power Disconnect
Cable
Cabinet
110VAC Supply Cable
Range Hood
10” Ductwork
Fan
7” to 10” adaptor set
D1000-I_-DF D1000-I_-DF-NFPA101
D1000-I_-WF D1000-I_-WF-NFPA101
Plenum Ready Supply
Cable to Fan
Power Disconnect
Cable
Cabinet
110VAC Supply Cable
Range Hood
12” Ductwork
Fan
Air
Flow
7” to 12” adaptor set
Plenum Ready Supply
Cable to Fan
Power Disconnect
Cable
Cabinet
110VAC Supply Cable
Range Hood
7” Ductwork
Fan
Air
Flow
Air
Flow
