The D1000
Installation and
Service
Version 2.1
2
System Anatomy
Recirculating Vent
(recirculating model)
Power Switch
Reset Switch
Extinguisher Pressure Gauge
Electrical Disconnect (Black Tape)
110 VAC Power Supply (Red Tape)
Junction Box
Thumbscrew (to remove vent) -on some models
Thumbscrews (2x) (inline models)
Back Support Mounting Bracket
Fan Speed Knob
Light Switch
Discharge Nozzles
(with protective caps)
Fusible Link
Light Bulb
Low Temperature Switches
High Temperature
Switch
Thumb Nut (3x)
Grease Tray
Grease Filter
LED Status Light
