The D1000
Installation and
Service
Version 2.1
1
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PER-
SONS, OBSERVE THE FOLLOWING:
1. Use this unit only in the manner intended by the manufacturer. If you
have questions, contact the manufacturer at the address or telephone
number listed on the front cover of this manual.
2. Before servicing or cleaning unit, switch power off at service panel and
lock the service disconnecting means to prevent power from being
switched on accidentally. When the service disconnecting means can-not
be locked, securely fasten a prominent warning device, such as a tag, to
the service panel.
3. Installation work and electrical wiring must be done by a qualied per-
son(s) in accordance with all applicable codes and standards, in-cluding
re-rated construction codes and standards.
4. Sufcient air is needed for proper combustion and exhausting of gases
through the ue (chimney) of fuel burning equipment to prevent back-
drafting. Follow the heating equipment manufacturer’s guideline and
safety standards such as those published by the National Fire Protection
Association (NFPA), and the American Society of Heating, Refrigeration
and Air Conditioning Engineers (ASHRAE), and the local code authori-
ties.
5. When cutting or drilling into wall or ceiling, do not damage electrical
wiring and other hidden utilities.
6. To reduce the risk of re or electric shock, do not use this range hood
with an additional speed control device.
7. Ducted fans must always be vented to the outdoors.
8. To reduce the risk of re, use only metal ductwork.
9. Use with approved wiring only.
10. This unit must be grounded.
TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:
1. Never leave surface units unattended at high settings. Boilovers cause
smoking and greasy spillovers that may ignite. Heat oils slowly on low or
medium settings.
2. Always turn hood ON when cooking at high heat or when cooking aming
foods.
3. Clean ventilating fans frequently. Grease should not be allowed to accu-
mulate on fan or lter.
4. Use proper pan size. Always use cookware appropriate for the size of the
surface element.
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A
RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING:*
1. SMOTHER FLAMES with a close-tting lid, cookie sheet, or metal tray,
then turn off the burner. BE CAREFUL TO PREVENT BURNS. If the
ames do not go out immediately, EVACUATE AND CALL THE FIRE
DEPARTMENT.
2. NEVER PICK UP A FLAMING PAN — You may be burned.
3. DO NOT USE WATER, including wet dishcloths or towels - violent steam
explosion will result.
4. Use an extinguisher ONLY if:
A. You know you have a Class ABC extinguisher and you already know
how to operate it.
B. The re is small and contained in the area where it started.
C. The re department is being called.
D. You can ght the re with your back to an exit.
* Based on “Kitchen Fire Safety Tips” published by NFPA.
WARNING
1. For general ventilating use only. Do not use to exhaust hazardous or
explosive materials and vapors.
2. To avoid motor bearing damage and noisy and/or unbalanced impel
-
lers, keep drywall spray, construction dust, etc. off power unit.
3. For best capture of cooking impurities and performance of re extin-
guisher, your range hood should be mounted so that the bottom of
the hood is 18-30” above the cooking surface, depending on model.
4. Please read specication sheets for further information and require-
ments.
!
CAUTION
TABLE OF CONTENTS
READ AND SAVE THESE INSTRUCTIONS
1. System Anatomy pg 2
2. Sample Elevations pg 3
3. Preparing thr Install location pg 5
4. Range Element Disconnect install pg 8
5. Installing The D1000 pg 10
6. Fire Alarm System Connections pg 11
7. Manual Pull Station Installation pg 12
8. Test Tank & Demonstration pg 13
9. Electrical Schematic pg 14
10. Accessing The Interals pg 16
11. Maintnence pg 17
12. D1000 Operating System pg 19
13. PLC Schematic pg 22
14. After an Actuation pg 24
15. Ducting and Airow pg 27
16. Spare Parts pg 28
17. Warranty Statement pg 29
18. NFPA101 -F & -R Installation Appendix A
DISCLAIMER: Denlar Fire Protection LLC, shall not be liable for errors contained in this
Manual or for incidental, consequential damages in connection with the furnishing,
performance or use of this information. Denlar Fire Protection makes no warranty
of any kind with regard to this information, including, but not limited to the implied
warranties of merchantability and tness for a particular purpose.
