Denon AVR-1707 Service Manual

103
AVR-1707/1507/687/587/487
45A nsp 00D 963 0289 108 PRE AMP P.W.B. Assy
1707E3,687E3
7025HK0511012 1 *
45A nsp 00D 963 0289 205 PRE AMP P.W.B. Assy
1707E2
7025HK0511022 1 *
45A nsp 00D 963 0289 302 PRE AMP P.W.B. Assy
1707EUT
7025HK0511032 1 *
45A nsp 00D 963 0289 409 PRE AMP P.W.B. Assy
1507E3,587E3
7025HK0510012 1 *
45A nsp 00D 963 0289 506 PRE AMP P.W.B. Assy
1507E2
7025HK0510022 1 *
45A nsp 00D 963 0289 603 PRE AMP P.W.B. Assy
487E3
7025HK0510062 1 *
35 2CH-AMP P.W.B.
45 PRE AMP P.W.B.
66A nsp 00D 963 0289 700 INPUT P.W.B. Assy
1707E3,687E3
7025HK0511064 1 *
66A nsp 00D 963 0289 807 INPUT P.W.B. Assy
1707E2
7025HK0511024 1 *
66A nsp 00D 963 0289 904 INPUT P.W.B. Assy
1707EUT
7025HK0511034 1 *
66A nsp 00D 963 0290 003 INPUT P.W.B. Assy
1507E3,587E3
7025HK0510014 1 *
66A nsp 00D 963 0290 100 INPUT P.W.B. Assy
1507E2
7025HK0510024 1 *
66A nsp 00D 963 0290 207 INPUT P.W.B. Assy
487E3
7025HK0510064 1 *
66 INPUT P.W.B.
78 MIC P.W.B.
64A nsp 00D 963 0290 304 C-S VIDEO 1 P.W.B. Assy
1707E3,687E3
7025HK0511017 1 *
64A nsp 00D 963 0290 401 C-S VIDEO 1 P.W.B. Assy
1707E2
7025HK0511027 1 *
64A nsp 00D 963 0290 508 C-S VIDEO 1 P.W.B. Assy
1707EUT
7025HK0511037 1 *
64A nsp 00D 963 0290 605 C-S VIDEO 2 P.W.B. Assy
1507E3,587E3
7025HK0510019 1 *
64A nsp 00D 963 0290 702 C-S VIDEO 2 P.W.B. Assy
1507E2
7025HK0510029 1 *
64A nsp 00D 963 0290 809 C-S VIDEO 2 P.W.B. Assy
487E3
7025HK0510069 1 *
61 COMP-V1 P.W.B.
62 V-CNT DOWN 1/2 P.W.B.
63 V-CNT UP 1/2 P.W.B.
64 C-S VIDEO1 P.W.B.
76 V-CNT DOWN 2/2 P.W.B.
Except for 1507E3,487E3
77 V-CNT UP 2/2 P.W.B.
Except for 1507E3,487E3
65A 00D 963 0290 906 DSP1 P.W.B. Assy
1707E3,687E3,1707E2,
1707EUT,1507E2
7025HK0511066 1 *
65A 00D 963 0290 906 DSP2 P.W.B. Assy
1507E3,587E3
7025HK0511066 1 *
65A 00D 963 0291 002 DSP2 P.W.B. Assy
487E3
7025HK051006A 1 *
65 DSP1 P.W.B. *
65 DSP2 P.W.B.
1 00D 963 0291 109 PANEL FRONT
1707E3
3067212191200S 1 *
1 00D 963 0291 206 PANEL FRONT
687E3
3067212201200S 1 *
1 00D 963 0291 303 PANEL FRONT
587E3
3067212201310S 1 *
1 00D 963 0291 400 PANEL FRONT
1707EUT
3067212191310S 1 *
1 00D 963 0291 507 PANEL FRONT
1707E2
3067212191300S 1 *
1 00D 963 0291 604 PANEL FRONT
1507E2
3067212191320S 1 *
1 00D 963 0291 701 PANEL FRONT
1507E3
3067211751400S 1 *
1 00D 963 0291 808 PANEL FRONT
487E3
3067212201300S 1 *
2 00D 963 0051 501 BADGE
Black
5630210028000S 1
2 00D 963 0051 514 BADGE
Premium Silver
5630210028100S 1
2 00D 963 0051 527 BADGE
Silver
5630210028200S 1
3 00D 963 0138 301 KNOB INPUT
Black
5087210961000S 1
3 00D 963 0240 202 KNOB INPUT
Premium Silver
5087210961110S 1
3 00D 963 0141 505 KNOB INPUT
Silver
5087210961100S 1
4 00D 963 0291 905 WINDOW DISPLAY
1707E3,687E3
50772119220E0S 1 *
4 00D 963 0237 309 WINDOW DISPLAY
1707EUT
50772119220A0S 1
Ref. No. nsp Part No. Part Name Remarks ETRO Q'ty New

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
