Denon AVR-1707 Service Manual

46
AVR-1707/1507/687/587/487
D152,153 00D 963 0058 407 D,SWITCHING IN4007 K000400700520S
D158-160 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
ZD101C 00D 963 0279 804 D,ZENER 0.2W 4.3V UDZ S K06604R34P410S
ZD101FL 00D 963 0279 804 D,ZENER 0.2W 4.3V UDZ S K06604R34P410S
ZD101FR 00D 963 0279 804 D,ZENER 0.2W 4.3V UDZ S K06604R34P410S
ZD101SL 00D 963 0279 804 D,ZENER 0.2W 4.3V UDZ S K06604R34P410S
ZD101SR 00D 963 0279 804 D,ZENER 0.2W 4.3V UDZ S K06604R34P410S
ZD102C 00D 963 0295 503 D,ZENER 0.2W 3.6V UDZ S K06603R64P400S
ZD102FL 00D 963 0295 503 D,ZENER 0.2W 3.6V UDZ S K06603R64P400S
ZD102FR 00D 963 0295 503 D,ZENER 0.2W 3.6V UDZ S K06603R64P400S
ZD102SL 00D 963 0295 503 D,ZENER 0.2W 3.6V UDZ S K06603R64P400S
ZD102SR 00D 963 0295 503 D,ZENER 0.2W 3.6V UDZ S K06603R64P400S
ZD133,134 00D 963 0046 202 D,ZENER MTZJ18B K06018R044520S
ZD136 00D 963 0058 601 D,ZENER MTZJ12B K06012R044520S
ZD154 00D 960 0095 704 D,ZENER MTZJ6.2B K06006R244520S
ZD157 00D 963 0219 903 D,ZENER MTZJ16B K06016R044520S
ZD341,342 00D 960 0095 500 D,ZENER MTZJ5.1B K06005R144520S
LED901 00D 963 0148 605 LED SML1216W RED/GREEN K500052600030
RESISTORS GROUP
R104C 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220F
R104FL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220F
R104FR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220F
R104SL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220F
R104SR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220F
R105C 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220F
R105FL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220F
R105FR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220F
R105SL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220F
R105SR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220F
R106C 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R106FL 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R106FR 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R106SL 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R106SR 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R107C 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R107FL 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R107FR 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R107SL 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R107SR 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R108C 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R108FL 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R108FR 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R108SL 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R108SR 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R109C 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R109FL 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R109FR 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R109SL 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R109SR 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R110C 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R110FL 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R110FR 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R110SL 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R110SR 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R111C 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R111FL 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R111FR 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R111SL 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R111SR 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820F
R118C 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020F
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
