Page #102 background imageLoading...
Page #102 background image
102
AVR-1707/1507/687/587/487
PARTS LIST OF EXPLODED VIEW
*本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
*"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
1707E3 : U.S.A. & Canada model 1707E2 : Europe model 1707EUT : Taiwan R.O.C. model
687E3 : U.S.A. & Canada model (AVR686)
1507E3 : U.S.A. & Canada model 1507E2 : Europe model
587E3 : U.S.A. & Canada model (AVR586) 487E3 : U.S.A. & Canada model (AVR486)
Black : Black model
Premium Silver
: Premium Silver model
Silver
: Silver model
Ref. No. nsp Part No. Part Name Remarks ETRO Q'ty New
43A nsp 00D 963 0286 509 MAIN P.W.B. Assy
1707E3,687E3
7025HK0511010 1 *
43A nsp 00D 963 0286 606 MAIN P.W.B. Assy
1707E2
7025HK0511020 1 *
43A nsp 00D 963 0286 703 MAIN P.W.B. Assy
1707EUT
7025HK0511030 1 *
43A nsp 00D 963 0286 800 MAIN P.W.B. Assy
1507E3,587E3
7025HK0510010 1 *
43A nsp 00D 963 0286 907 MAIN P.W.B. Assy
1507E2
7025HK0510020 1 *
43A nsp 00D 963 0287 003 MAIN P.W.B. Assy
487E3
7025HK0510060 1 *
14 HEADPHONE P.W.B.
20 TACT SW P.W.B.
43 MAIN P.W.B.
!47 AC OUTLET P.W.B.
60A nsp 00D 963 0287 100 CPU P.W.B. Assy
1707E3,687E3
7025HK0511011 1 *
60A nsp 00D 963 0287 207 CPU P.W.B. Assy
1707E2
7025HK0511021 1 *
60A nsp 00D 963 0287 304 CPU P.W.B. Assy
1707EUT
7025HK0511031 1 *
60A nsp 00D 963 0287 401 CPU P.W.B. Assy
1507E3,587E3
7025HK0510011 1 *
60A nsp 00D 963 0287 508 CPU P.W.B. Assy
1507E2
7025HK0510021 1 *
60A nsp 00D 963 0287 605 CPU P.W.B. Assy
487E3
7025HK0510061 1 *
! 15 POWER SW P.W.B.
21 FRONT P.W.B.
25 V-AUX P.W.B.
60 CPU P.W.B.
59A nsp 00D 963 0287 702 CNT P.W.B. Assy
1707E3,687E3
7025HK0511013 1 *
59A nsp 00D 963 0287 809 CNT P.W.B. Assy
1707E2
7025HK0511023 1 *
59A nsp 00D 963 0287 906 CNT P.W.B. Assy
1707EUT
7025HK0511033 1 *
59A nsp 00D 963 0288 002 CNT P.W.B. Assy
1507E3,587E3
7025HK0510013 1 *
59A nsp 00D 963 0288 109 CNT P.W.B. Assy
1507E2
7025HK0510023 1 *
59A nsp 00D 963 0288 206 CNT P.W.B. Assy
487E3
7025HK0510063 1 *
59 CNT P.W.B.
69A nsp 00D 963 0288 303 8CH-EXT XM P.W.B. Assy
1707E3
7025HK0511015 1 *
69A nsp 00D 963 0288 400 8CH-EXT XM P.W.B. Assy
687E3
7025HK0511065 1 *
69A nsp 00D 963 0288 507 8CH-EXT XM P.W.B. Assy
1507E3
7025HK0510015 1 *
69A nsp 00D 963 0288 604 8CH-EXT XM P.W.B. Assy
587E3
7025HK0510055 1 *
69A nsp 00D 963 0289 001 8CH-EXT XM P.W.B. Assy
487E3
7025HK0510065 1 *
69 8CH-EXT XM P.W.B.
69A nsp 00D 963 0288 701 8CH-EXT P.W.B. Assy
1707E2
7025HK0511028 1 *
69A nsp 00D 963 0288 808 8CH-EXT P.W.B. Assy
1707EUT
7025HK0511038 1 *
69A nsp 00D 963 0288 905 8CH-EXT P.W.B. Assy
1507E2
7025HK0510028 1 *
69 8CH-EXT P.W.B.
