127
AVR-1707/1507/687/587/487
DOCUMENTS FOR WEEE
Details of Recycle parts
＊ You have to remove the parts that marked “WEEE Mark ◆ “ when the recycling processing. (Europe model only)
Ref. No.
WEEE
Mark
Part Name Material Q'ty
1 PANEL FRONT ABS 1
2 BADGE Aluminum 1
3 KNOB INPUT ABS 1
4 WINDOW DISPLAY PVC 1
5 COVER RCA ABS 1
6 KNOB VOLUME ABS 1
7 KNOB SELECT ABS 1
8 BRACKET SIDE L/R Steel 2
9 LENS STANDBY PMMA 1
10
◆
BUTTON STANDBY Aluminum+ABS 1
11
◆
BUTTON POWER Aluminum+ABS 1
12 LENS LED PMMA 1
14
◆
HEADPHONE P.W.B. Complex 1
15
◆
POWER SW P.W.B. Complex 1
17 BUTTON 3KEY(A) ABS 1
20
◆
TACT SW P.W.B. Complex 1
21
◆
FRONT P.W.B. Complex 1
22 BUTTON 4KEY ABS 1
23 BUTTON 3KEY ABS 1
25
◆
V-AUX P.W.B. Complex 1
26 BRACKET HEAT SINK-F Steel 1
27 TR PNP 2SB1560-Y Complex 5
28 POSISTOR P43T7D330BW16 Complex 1
29 TR NPN 2SC3964 Complex 5
30 CABINET TOP PVC+Steel 1
31 TR NPN 2SD2390-Y Complex 5
32 HEAT SINK MAIN Aluminum 1
33 BRACKET HEAT SINK-B Steel 1
34 BRACKET PCB Steel 2
35
◆
2CH-AMP P.W.B. Complex 1
39 BRACKET TRANS Steel 1
40 POWER TRANS Complex 1
43
◆
MAIN P.W.B. Complex 1
45
◆
PRE AMP P.W.B. Complex 1
47
◆
AC OUTLET P.W.B. Complex 1
49 STOPPER CORD AC PA 1
50
◆
AC CORD Complex 1
51 CHASSIS MAIN Steel 1
52 FOOT ABS 4
53 CUSHION FOOT Rubber 4
54 CUSHION SIDE Rubber 2
56 SUPPORTER PCB PA 3
57 BRACKET SUPPORTER Steel 1
58 SUPPORTER P.C. PA 1
59
◆
CNT P.W.B. Complex 1
60
◆
CPU P.W.B. Complex 1
61
◆
COMP-V1 P.W.B. Complex 1
62
◆
V-CNT DOWN 1/2 P.W.B. Complex 1
63
◆
V-CNT UP 1/2 P.W.B. Complex 1
64
◆
C-S VIDEO1 P.W.B. Complex 1
To Next Page
