Denon AVR-1707 Service Manual

47
AVR-1707/1507/687/587/487
R118FL 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020F
R118FR 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020F
R118SL 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020F
R118SR 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020F
R119C 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020F
R119FL 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020F
R119FR 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020F
R119SL 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020F
R119SR 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020F
R135,136 00D 963 0144 502 R,CEMENT 0.1-J 5W C141R10069000S
R141,142 00D 963 0216 003 R,METAL FILM 0.22-J,1W C060R22065050S
R148,149 00D 963 0216 003 R,METAL FILM 0.22-J,1W C060R22065050S
R151 00D 963 0232 809 R,METAL FILM 10-J,1/4W C060010063520S
R154 00D 963 0244 305 R,METAL FILM 2.2M 0.5W 1707E3,687E3,1707EUT C060022564520S
R179 00D 963 0232 906 R,METAL FILM 47K-F,1/4W C060047343530S
R184 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020F
R901,902 00D 960 9009 270 R,METAL FILM 470-J,2W C060047166520S
VR101-105 00D 960 0091 601 VR,SEMI CERMET 1KB C544102015130P
CAPACITORS GROUP
C101C 00D 963 0234 506 C,ELECT 47UF-M/50V(Pb Free) D040470087070F
C101FL 00D 963 0234 506 C,ELECT 47UF-M/50V(Pb Free) D040470087070F
C101FR 00D 963 0234 506 C,ELECT 47UF-M/50V(Pb Free) D040470087070F
C101SL 00D 963 0234 506 C,ELECT 47UF-M/50V(Pb Free) D040470087070F
C101SR 00D 963 0234 506 C,ELECT 47UF-M/50V(Pb Free) D040470087070F
C102C 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C102FL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C102FR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C102SL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C102SR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C103C 00D 963 9003 084 C,CERAMIC100PF-K/500V D00410106D050S
C103FL 00D 963 9003 084 C,CERAMIC100PF-K/500V D00410106D050S
C103FR 00D 963 9003 084 C,CERAMIC100PF-K/500V D00410106D050S
C103SL 00D 963 9003 084 C,CERAMIC100PF-K/500V D00410106D050S
C103SR 00D 963 9003 084 C,CERAMIC100PF-K/500V D00410106D050S
C104C 00D 963 9003 084 C,CERAMIC100PF-K/500V D00410106D050S
C104FL 00D 963 9003 084 C,CERAMIC100PF-K/500V D00410106D050S
C104FR 00D 963 9003 084 C,CERAMIC100PF-K/500V D00410106D050S
C104SL 00D 963 9003 084 C,CERAMIC100PF-K/500V D00410106D050S
C104SR 00D 963 9003 084 C,CERAMIC100PF-K/500V D00410106D050S
C105C 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V D005223594520S
C105FL 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V D005223594520S
C105FR 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V D005223594520S
C105SL 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V D005223594520S
C105SR 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V D005223594520S
C107C 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C107FL 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C107FR 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C107SL 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C107SR 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C131-135 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C136,137 00D 963 0149 400 CAP.E.GENERIC 10000UF/63V N211210388110F
C138 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C138A 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C141-143 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060P
C144 00D 963 0217 109 C,ELECT 3300UF-M/35V D040332085010F
C145 00D 963 9003 123 C,ELECT 1000UF-M/35V D040102085040F
C146 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C148 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C150-152 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060P
C153 00D 963 0021 104 C,ELECT 6800UF-M/16V D040682083000F
C154 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
