Denon AVR-1707 Service Manual

60
AVR-1707/1507/687/587/487
8CH-EXT XM P.W.B. UNIT ASSY (for AVR-1707/687 E3 model)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC201X 00D 262 3517 907 F2602-01-TR
IC202X 00D 262 2517 908 SN74LV08APW-EL2 +REF
IC203X 00D 262 2813 903 SN74AHCT08PW-EL2 +C
IC204X 00D 963 0295 309 IC LM1117S J126111733030S
IC205X 00D 963 0294 902 IC AK4385 J042438500010S
IC206 00D 963 0202 305 IC NJM2068M J121206800020S
IC206X 00D 399 1055 909 FCX-02(45.1584MHz)
IC207X 00D 263 1092 003 BA05T
IC208X 00D 963 0218 807 IC BU4094BCF J040140940030P
IC209X 00D 262 2813 903 SN74AHCT08PW-EL2 +C
IC401 00D 960 0296 105 IC CJ7812F J126781200220S
IC402 00D 960 0174 104 IC CXA1511M 1707E3 J030151100010S
Q201R 00D 963 0121 402 TR KRA104S J520010400210S
Q201X 00D 963 0120 801 TR KRC102S J522010200210S
Q203X 00D 963 0120 801 TR KRC102S J522010200210S
Q204X 00D 963 0120 801 TR KRC102S J522010200210S
Q206X 00D 963 0120 704 TR KRA102S J520010200210S
Q207X 00D 963 0120 704 TR KRA102S J520010200210S
Q208X 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q209X 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q210X 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q211X 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q401 00D 960 0097 003 TR KRA104M 1707E3 J6000104M0010S
Q666A 00D 963 0044 301 TR KTC2875B 1707E3 J5222875B0010S
Q667A 00D 963 0044 301 TR KTC2875B J5222875B0010S
Q668A 00D 963 0044 301 TR KTC2875B 1707E3 J5222875B0010S
Q669A 00D 963 0044 301 TR KTC2875B J5222875B0010S
D201X 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D202X 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D203X 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D204X 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D205X 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D206X 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
D207X 00D 963 0219 709 D,SWITCHING 1N4148W K005041480020S
ZD401 00D 960 0095 704 D,ZENER MTZJ6.2B 1707E3 K06006R244520S
RESISTORS GROUP
R273X 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
R274X 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
CAPACITORS GROUP
C201X nsp 00D 963 9006 528 C,CERAMIC 20PF-J/50V D010200167160S
C202X nsp 00D 963 9006 528 C,CERAMIC 20PF-J/50V D010200167160S
C203X nsp 00D 963 9006 528 C,CERAMIC 20PF-J/50V D010200167160S
C204X nsp 00D 963 9006 528 C,CERAMIC 20PF-J/50V D010200167160S
C205X nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C206X nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C207X nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C208X 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C209X nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C212X nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C213X nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V D011102777160S
C215X 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C216X 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C217X nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C218X nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C219X nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V D011102777160S

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
