Denon AVR-1707 Service Manual

128
AVR-1707/1507/687/587/487
65
◆
DSP1 P.W.B. Complex 1
66
◆
INPUT P.W.B. Complex 1
69
◆
8CH-EXT P.W.B. Complex 1
70
◆
TUNER PACK Complex 1
71 CHASSIS BACK Steel 1
72 SHEET CABINET Rubber 1
73 BRACKET SIDE Steel 1
76
◆
V-CNT DOWN 2/2 P.W.B. Complex 1
77
◆
V-CNT UP 2/2 P.W.B. Complex 1
78
◆
MIC P.W.B. Complex 1
80 WASHER Steel 1
84 COVER SAFETY PC 1
85 COVER HOLDER POM 6
87
◆
CE68W1J103M(DL) Complex 2
88 POWER TRANS(Sub) Complex 1
A SCREW(3X8 B-TYPE ZNY/BH) Steel 63
B SCREW(3X8 ZnY WASHER PI12) Steel 4
C SCREW(3X15 B-TYPE ZNY/BH) Steel 2
D SCREW(3X10 B-TYPE(DOT) BK/BH) Steel 36
E SCREW(3X14 P+S-WASHER ZNY/HH) Steel 22
F SCREW(3X17 B-TYPE ZNY/BH) Steel 3
G SCREW(4X8 B-TYPE(DOT) BK/BH) Steel 6
H SCREW(4X10 P+S-WASHER ZNY/BH) Steel 1
I SCREW(3X8 BK WASHER PI12) Steel 1
J SCREW(4X6 S-TYPE ZNY/BH) Steel 6
K SCREW(3X5 B-TYPE ZNY/BH) Steel 2
L SCREW(3X8 PI9.5 B-TYPE ZNY) Steel 2
Ref. No.
WEEE
Mark
Part Name Material Q'ty

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
