Denon AVR-1707 Service Manual

107
AVR-1707/1507/687/587/487
PARTS LIST OF PACKING & ACCESSORIES (for AVR-1507/587/487 model)
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
1507E3 : U.S.A. & Canada model (AVR-1507) 587E3 : U.S.A. & Canada model (AVR-587) 487E3 : U.S.A. & Canada model (AVR-487)
E2 : Europe model (AVR-1507)
10 - S.S LIST 5777001620018S 1
11 - BATTERY DRY G670001R50190 2
12 - UPC LABEL E3 5507002360050S 1 *
12 - UPC LABEL E2 5507002360060S 1 *
12 - UPC LABEL 687E3 5507002360070S 1 *
13 - CONTROL CARD 5500014920010S 1
14 nsp 00D 963 0241 405 PE,SHEET 6327040059000S 1
15 00D 321 0038 005 MIC CONDENSER DM-S205 1
16 00D 963 0268 006 POLY BAG 6330210222000S 1
20 00D 963 0110 303 COLOR LABEL(SILVER) E2 5507020170340S 2
20 00D 963 0230 209 COLOR LABEL(PREMIUM SILVER) EUT 5507020170680S 2
21 - LABEL KORIN (BOX) EUT 5507030000470S 1
22 - LABEL ORIGIN (BOX) EUT 5507003010040S 1
23 - LABEL ORIGIN (BOX) EUT 5507003010031S 1
Ref. No. nsp Part No. Part Name Remarks ETRO Q'ty New
1 00D 513 4107 007 XM SHEET 1507E3,587E3,487E3 1
2 00D 963 0285 005 INSTRUCTION MANUAL 1507E3 5707210130010S 1 *
2 00D 963 0285 005 INSTRUCTION MANUAL 487E3 5707210130010S 1 *
2 00D 963 0285 102 INSTRUCTION MANUAL 1507E2 5707210130020S 1 *
2 00D 963 0285 209 INSTRUCTION MANUAL 587E3 5707210130040S 1 *
3 00D 231 0089 007 AM LOOP ANTENNA 1
4 00D 963 0158 006 FM ANTENNA WIRE E605010070001S 1
4 - BATTERY DRY G670001R50190 2
5 00D 963 0286 208 REMOTE CONTROL RC-1048 1507E3,587E3 8300010480010S 1 *
5 00D 963 0286 305 REMOTE CONTROL RC-1049 1507E2 8300010490010S 1 *
5 00D 963 0286 402 REMOTE CONTROL RC-1050 487E3 8300010500010S 1 *
6 nsp 00D 963 0045 106 POLY BAG 6330000240000S 1
7 00D 963 0193 101 CUSHION,SNOW 6230210154001S 1
8 00D 963 0285 607 BOX GIFT 1507E3 6007210310570S 1 *
8 00D 963 0301 808 BOX GIFT 1507E2 6007210310690S 1 *
8 00D 963 0285 704 BOX GIFT 587E3 6007210310600S 1 *
8 00D 963 0285 801 BOX GIFT 487E3 6007210310610S 1 *
9 - WARRANTY CARD 1507E3,587E3,487E3 5777001610035S 1
10 - S.S LIST 5777001620018S 1
12 - UPC LABEL 1507E3 5507002360010S 1 *
12 - UPC LABEL 1507E2 5507002360020S 1 *
12 - UPC LABEL 587E3 5507002360030S 1 *
12 - UPC LABEL 587E2 5507002360040S 1 *
13 - CONTROL CARD 5500014920010S 1
14 nsp 00D 963 0241 405 PE,SHEET 6327040059000S 1
15 00D 321 0038 005 MIC CONDENSER DM-S205 1507E2 1
16 00D 963 0268 006 POLY BAG 6330210222000S 1
20 00D 963 0110 303 COLOR LABEL(SILVER) 1507E2 5507020170340S 1
Ref. No. nsp Part No. Part Name Remarks ETRO Q'ty New

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
