49
AVR-1707/1507/687/587/487
! F102 00D 963 0236 106 FUSE T8A/250V 1707E3,687E3,1707EUT N751228001110S
! F102 00D 963 0104 704 FUSE T3.15A/250V 1707E2 N751223151110S
F101A nsp 00D 960 0005 804 HOLDER,FUSE CLIP G645000050010
F101B nsp 00D 960 0005 804 HOLDER,FUSE CLIP G645000050010
F102A nsp 00D 960 0005 804 HOLDER,FUSE CLIP G645000050010
F102B nsp 00D 960 0005 804 HOLDER,FUSE CLIP G645000050010
G901 00D 963 0257 907 CN,WIRE 160MM/1P N602141610310F
GND101-103 - TERMINAL EARTH 3790040886000S
L101C nsp 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000F
L101FL nsp 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000F
L101FR nsp 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000F
L101SL nsp 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000F
L101SR nsp 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000F
RLY101-104 00D 960 0181 702 RELAY G5PA-28 24V 5A G680240502020S
RLY105 00D 963 0218 506 RELAY BC3-24 24V 2A G680240202040F
RLY106 00D 963 0218 205 RELAY G5PA-1 DC9V 250V/5A G680090102010F
RLY107 00D 960 0181 702 RELAY G5PA-28 24V 5A G680240502020S
SW901 00D 963 0200 103 SW,TACT SKHV10920A G180000270010S
TP101-105 nsp 00D 960 0161 405 CN.WAFER 3P L101530140310S
VEC303 00D 963 0095 208 SW,ENCODER EC16B24SA G121162400040S
- HEAT SINK 2120043538050S
- HEAT SINK 2120044308010S
! 00D 963 0232 100 STAND BY TRANS 120V/60HZ 1707E3,687E3,1707EUT 8200350150200S
! 00D 963 0215 606 STAND BY TRANS 230V/50HZ 1707E2 8200350150210S
nsp 00D 963 0018 007 SCREW, 3*8 B-TYPE ZNY/BH B020030081B10S
00D 963 0158 608 2P TER, SP G611201A0200YS
00D 963 0119 906 8P TER, SP G614801A0200YS
00D 963 0294 708 JACK,D6.5 PHONE G402PJ612AG0YS
! 00D 960 0181 508 AC OUTLET(E3) 1707E3,687E3,1707EUT G435204004010S
! 00D 960 0143 203 AC OUTLET(E2) 1707E2 G435040110000S
00D 963 0247 001 LABEL, FUSE (F102) 1707E2 5527200040030S
- COVER CAPACITOR 1707E2 4310002640010S
Ref. No. nsp Part No. Part Name Remarks Q'ty New
