Denon AVR-1707 Service Manual

62
AVR-1707/1507/687/587/487
8CH-EXT (E2) P.W.B. UNIT ASSY (for AVR-1707 E2/EUT model)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC401 00D 960 0296 105 IC CJ7812F J126781200220S
Q666A 00D 960 0196 603 TR KTC2874B J502287400010S
Q668A 00D 960 0196 603 TR KTC2874B J502287400010S
CAPACITORS GROUP
C401 00D 963 9005 804 C,ELECT 100UF-M/25V D040101084060F
C402 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C403,404 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C481SBL nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C481SBR nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C481SL nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C481SR nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C606A nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C647 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
OTHERS PARTS GROUP
BD401,402 nsp 00D 963 0154 602 COIL,BEAD 7610010030000S
CN401 nsp 00D 963 0236 902 CN.WAFER 12P L101100031210S
CN402 nsp 00D 963 0086 709 CN.WAFER 11P L101100031110S
CN404 nsp 00D 963 0205 700 CN.WAFER 5P L101100030510S
CP401A 00D 963 0149 303 CN.FPC 15P L131111500010F
00D 963 0146 005 TER,RCA 1PIN G600107A0000YS
00D 963 0146 209 TER,RCA 4PIN G602405B01000S

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
