Denon AVR-1707 Service Manual

76
AVR-1707/1507/687/587/487
C210 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V 1507E2 D011103777160S
C211,212 00D 963 9004 614 C,CERAMIC 27PF-J/50V 1507E2 D010270167160S
C221 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C261,262 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C267-270 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C271,272 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C275 nsp 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V D011104597160S
C278 nsp 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V D011104597160S
C279 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C291,292 00D 963 9004 517 C,CERAMIC 0.022UF-Z/50V D004223597050S
C293 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V D005103773530S
C294 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C295 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V D005103773530S
C301 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C302 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C303 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C304 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V D005223594520S
C305 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C306 00D 963 0216 401 C,FILM 0.1UF-J/100V D02010406C060P
C307 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C308,309 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060P
C310 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C311 nsp 00D 963 0233 701 C,CERAMIC 30PF-J/50V D010300167160S
C312 00D 963 9005 859 C,ELECT 47UF-M/16V D040470083060F
C313 - C,FILM 0.047UF-J/100V D02047306C070S
C321 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V D011102777160S
C322 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C324,325 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C326X nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C331,332 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V D005103773530S
C335,336 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V D005103773530S
C343X nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C381 00D 963 9005 862 C,ELECT 47UF-M/16V 1507E2 D040470083080F
C381A 00D 963 9005 862 C,ELECT 47UF-M/16V 1507E3,587E3,487E3 D040470083080F
C382,383 nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V 1507E2 D010101167160S
C382A nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V 1507E3,587E3,487E3 D010101167160S
C383A nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V 1507E3,587E3,487E3 D010101167160S
C384,385 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) 1507E2 D040010087150F
C384A 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) 1507E3,587E3,487E3 D040010087150F
C385A 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) 1507E3,587E3,487E3 D040010087150F
C386 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C387,388 nsp 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V 1507E2 D011104597160S
C387A nsp 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V 1507E3,587E3,487E3 D011104597160S
C388A nsp 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V 1507E3,587E3,487E3 D011104597160S
BC201 00D 254 4666 005 CE04W0H105ZC(FG)
OTHERS PARTS GROUP
BD201-203 nsp 00D 963 0154 602 BEAD,COIL 7610010030000S
BD301-303 nsp 00D 963 0234 603 COIL,BEAD MB-160808 1507E2 D340160800060S
BD301A nsp 00D 963 0234 603 COIL,BEAD MB-160808 1507E3,587E3,487E3 D340160800060S
BD302A nsp 00D 963 0234 603 COIL,BEAD MB-160808 1507E3,587E3,487E3 D340160800060S
BD303A nsp 00D 963 0234 603 COIL,BEAD MB-160808 1507E3,587E3,487E3 D340160800060S
CN201 00D 963 0245 906 CN,WIRE 240MM/6P 1507E2 L000241060020F
CN201A 00D 963 0245 906 CN,WIRE 240MM/6P 1507E3,587E3,487E3 L000241060020F
CN302 00D 963 0159 209 CN,WIRE 100MM/7P L000101070080P
CN902 00D 963 0246 002 CN,WIRE 80MM/3P L000800030110P
CN931 nsp 00D 963 0148 809 CN,WIRE 350MM/2P L000351020100P
CP201 nsp 00D 963 0097 604 CN.WAFER 6P L101220060000S
CP301A nsp 00D 963 0161 103 CN.FPC 23P L131112300010F
CP301B nsp 00D 963 0161 006 CN.FPC 23P L131102300010F
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
