Denon AVR-1707 Service Manual

84
AVR-1707/1507/687/587/487
C721 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C723 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070F
C726,727 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C731 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250F
C732 nsp 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V D011104597160S
C733 00D 963 0276 108 C,CERAMIC 3300PF-K/50V D011332777160S
C734 00D 963 0293 602 C,ELECT 1UF-M/50V(Pb Free) D040010087150F
C735 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250F
C736 nsp 00D 963 9004 711 C,CERAMIC 0.1UF-Z/50V D011104597160S
C737 00D 963 0276 108 C,CERAMIC 3300PF-K/50V D011332777160S
C738 00D 963 0293 602 C,ELECT 1UF-M/50V(Pb Free) D040010087150F
C741-750 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C750ZL 00D 960 9010 010 C,ELECT 4.7UF-M/50V 1507E3,587E3 D0404R7087250F
C750ZR 00D 960 9010 010 C,ELECT 4.7UF-M/50V 1507E3,587E3 D0404R7087250F
C751,752 00D 963 0234 205 C,ELECT 10UF-M/50V 1507E3,587E3 D040100087070F
C752ZL nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V 1507E3,587E3 D010101167160S
C752ZR nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V 1507E3,587E3 D010101167160S
C753ZL 00D 963 0234 205 C,ELECT 10UF-M/50V 1507E3,587E3 D040100087070F
C753ZR 00D 963 0234 205 C,ELECT 10UF-M/50V 1507E3,587E3 D040100087070F
C756,757 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V 1507E3,587E3 D011103777160S
C760,761 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C761FL nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C761FR nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C761SW nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C762 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C762FL nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C762FR nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C762SW nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C763 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C763FL nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C763FR nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C763SW nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C764 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C764FL nsp 00D 963 0223 805 C,CERAMIC 33PF-J/50V D010330167160S
C764FR nsp 00D 963 0223 805 C,CERAMIC 33PF-J/50V D010330167160S
C764SW nsp 00D 963 0233 808 C,CERAMIC 47PF-J/50V D010470167160S
C765 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C765FL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C765FR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C765SW 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C766,767 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C771,772 00D 963 9005 875 C,ELECT 47UF-M/25V D040470084070F
C773 00D 963 0293 602 C,ELECT 1UF-M/50V(Pb Free) D040010087150F
C791,792 00D 963 9005 875 C,ELECT 47UF-M/25V D040470084070F
OTHERS PARTS GROUP
CN551 00D 963 0184 407 CN,WIRE 160MM/14P L000161140050P
CN701 nsp 00D 963 0097 303 CN.WAFER 15P L101100031510S
CN701M 00D 963 0253 309 CN,WIRE 230MM/5P 1507E2 L000231050030F
CN702 nsp 00D 963 0086 204 CN.WAFER 19P L101100031910S
CN703 nsp 00D 963 0097 303 CN.WAFER 15P L101100031510S
CN704 00D 963 0256 801 CN.WAFER 10P L101100031010S
CP701M nsp 00D 963 0066 101 CN.WAFER 5P 1507E2 L101220050000S
RLY701 00D 963 0218 409 RELAY BC3-12 24V 2A 1507E3,587E3 G680240202030F
RLY702 00D 963 0218 409 RELAY BC3-12 24V 2A 1507E2 G680240202030F
00D 963 0094 005 CUSHION INPUT 4050210715000S
00D 963 0293 505 PLATE INPUT 4470210926000S
00D 963 0146 209 TER,RCA 4PIN G602405B01000S
00D 960 0268 803 TER,RCA 6PIN G603603B09000S
00D 963 0158 200 JACK,D3.5 EARPHONE 1507E2 G40132340000YS
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
