Denon AVR-1707 Service Manual

90
AVR-1707/1507/687/587/487
C821 00D 963 0216 906 C,ELECT 1000UF-M/6.3V D040102081060F
C823 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070F
C824 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C825 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250F
C830 00D 963 9005 901 C,ELECT 470UF-M/10V, D040471082060F
C832 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C833,834 nsp 00D 963 0233 905 C,CERAMIC 0.015UF-K/50V D011153777160S
C835 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C836,837 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V D011102777160S
C838-841 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C842 00D 963 0129 608 C,CERAMIC 15PF-J/50V D010150167160S
C844-846 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C847 00D 963 0129 608 C,CERAMIC 15PF-J/50V D010150167160S
C848-857 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C858 nsp 00D 963 0224 202 C,CERAMIC 0.022UF-K/25V D011223777160S
C859 nsp 00D 963 0246 507 C,CERAMIC 0.068UF-K/50V D010683777160S
C860 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C861,862 nsp 00D 963 9005 998 C,CERAMIC 24PF-J/50V D010240167160S
C863 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C864 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C864L 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C864R 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C865 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C865L nsp 00D 963 9005 723 C,CERAMIC 120PF-J/50V D010121167160S
C865R nsp 00D 963 9005 723 C,CERAMIC 120PF-J/50V D010121167160S
C866-869 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V D011103777160S
C869L nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C869R nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C870,871 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C871L 00D 963 0216 304 C,FILM 0.001UF-J/100V D02010206C060P
C871R 00D 963 0216 304 C,FILM 0.001UF-J/100V D02010206C060P
C872 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C873 00D 963 9005 804 C,ELECT 100UF-M/25V D040101084060F
C873C nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V D010681167160S
C873FL nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V D010681167160S
C873FR nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V D010681167160S
C873SBL nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V D010681167160S
C873SBR nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V D010681167160S
C873SL nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V D010681167160S
C873SR nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V D010681167160S
C873SW nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V D010681167160S
C874 00D 963 9005 804 C,ELECT 100UF-M/25V D040101084060F
C874C nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V D010561167160S
C874FL nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V D010561167160S
C874FR nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V D010561167160S
C874SBL nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V D010561167160S
C874SBR nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V D010561167160S
C874SL nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V D010561167160S
C874SR nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V D010561167160S
C874SW nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V D010561167160S
C875 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C875C 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C875FL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C875FR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C875SBL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C875SBR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C875SL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C875SR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C875SW 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C876 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V D011104577160S
C876C 00D 960 9008 611 C,FILM 0.0033UF-J/100V D02033206C060P
C876FL 00D 960 9008 611 C,FILM 0.0033UF-J/100V D02033206C060P
C876FR 00D 960 9008 611 C,FILM 0.0033UF-J/100V D02033206C060P
C876SBL 00D 960 9008 611 C,FILM 0.0033UF-J/100V D02033206C060P
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
