Denon AVR-1707 Service Manual

95
AVR-1707/1507/687/587/487
C/S VIDEO 2 P.W.B. UNIT ASSY
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC601 00D 963 0148 401 IC LA7956 J171795600010S
IC602 00D 963 0219 301 IC CJ7806 J126780600190S
IC621,622 00D 963 0148 401 IC LA7956 J171795600010S
IC651 00D 960 0175 200 IC BA7625 J171762500000P
IC652,653 00D 963 0083 304 IC BA7626 J171762600000P
Q601,602 00D 960 0005 202 TR KTC3198Y J5023198Y0000S
Q603-606 00D 963 0121 208 TR KRC107M J6020107M0010S
Q621,622 00D 960 0005 202 TR KTC3198Y J5023198Y0000S
Q623,624 00D 963 0121 208 TR KRC107M J6020107M0010S
Q625,626 00D 960 0005 202 TR KTC3198Y J5023198Y0000S
Q627,628 00D 963 0121 208 TR KRC107M J6020107M0010S
Q651-653 00D 960 0005 105 TR KTA1266Y J5001266Y0050S
D601,602 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D621,622 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D674A 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
CAPACITORS GROUP
C602-604 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C605,606 00D 963 9005 901 C,ELECT 470UF-M/10V D040471082060F
C607 00D 960 9009 924 C,ELECT 100UF-M/16V D040101083070F
C612,613 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C621-623 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C624,625 00D 963 9005 901 C,ELECT 470UF-M/10V D040471082060F
C626-628 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080F
C629,630 00D 963 9005 901 C,ELECT 470UF-M/10V D040471082060F
C632,633 nsp 00D 963 0234 001 C,CERAMIC 0.047UF-Z/50V D011473597160S
C634,635 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C651-656 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250F
C657 00D 963 9005 969 C,ELECT 4700UF-M/6.3V D040472081000F
C658,659 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070F
C660-662 00D 963 0293 806 C,ELECT 100UF-M/10V(Pb
Free)
D040101082090F
C663-665 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250F
C671,672 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C673 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V D005223594520S
C674 00D 963 0293 806 C,ELECT 100UF-M/10V(Pb
Free)
D040101082090F
C674A 00D 963 0234 506 C,ELECT 47UF-M/50V(Pb Free) D040470087070F
C681,682 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C683 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V D005223594520S
C691,692 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150F
C693 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V D005223594520S
C695,696 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070F
C707L nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C707R nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C708L nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
C708R nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V D010101167160S
OTHERS PARTS GROUP
CN601 nsp 00D 963 0086 301 CN.WAFER 18P L101100031810S
CN603-605 nsp 00D 963 0097 206 CN.WAFER 8P L101100030810S
CP603-605 nsp 00D 963 0097 400 CN.WAFER 8P L101100040810S
00D 963 0218 001 TER,RCA 2PIN G60122001000YS
00D 963 0146 209 TER,RCA 4PIN G602405B01000S
00D 963 0218 108 TER,RCA 3PIN G60630401000YS
- HEAT SINK 2120044338010S
00D 963 0146 306 TER,RCA 6PIN G603603B2600YS

Denon AVR-1707 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Total Harmonic Distortion (THD)	0.7 %
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Product color	Silver
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Digital Signal Processing (DSP)	Yes
HDMI in	0
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Optical drive included	No

Weight and Dimensions

Depth	417 mm
Width	434 mm
Height	147 mm
Weight	11400 g
