Denon AVR-1909 Service Manual

107
AVR-1909/789, AVC-1909
C517 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C518 00D9630217002 C,ELECT 3300UF-M/16V D040332083010S
C519 00D9630324704 C,ELECT 4700UF-M/16V D040472083200S
C520 00D9630021104 C,ELECT 6800UF-M/16V D040682083000S
C521-523 00D9630021900 C,FILM 0.047UF-J/100V D02047306C060S
C524 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) E3 D040010087150S
C524 00D9600298802 C,ELECT 470UF-M/6.3V E2, EA, JP D040471081070S
C525 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C528 00D9630324908 C,ELECT 4700UF-M/35V D040472085020S
C529 00D9630224707 C,ELECT 2200UF-M/35V E3 D040222085020S
C529 00D9600298909 C,ELECT 4700UF-M/35V E2, EA, JP D041472085010S
C530-532 00D9630021900 C,FILM 0.047UF-J/100V AVR1909, 789EA, AVC1909 D02047306C060S
C533-537 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C538 00D9630234205 C,ELECT 10UF-M/50V E3 D040100087070S
C538 00D9609010858 C,ELECT 470UF-M/25V E2, EA, JP D040471084130S
OTHERS PARTS GROUP
BKT501 nsp BRACKET 0.8t/SCREW E3
4010210196100S
BKT502 nsp BRACKET 0.8t/SCREW EA 4010210196100S
CLAMP101,102 nsp CLAMP WIRE(SOLDER) 4330000120000S
CLAMP104 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN502 nsp CN,WIRE 3P L000800030020S
CN505 nsp CN.WAFER 7P L101100030710S
CN506 nsp CN.WAFER 14P L101100031410S
CN507 nsp CN,WIRE 3P L000800030020S
CN704 nsp CN.WAFER 15P L101100031510S
CN705 nsp CN.WAFER 9P L101100030910S
CP501 nsp CN.WAFER 2CKT,YEL L108353280290S
CP503 nsp CN.WAFER 2CKT,RED L108353280280S
CP504 nsp CN.WAFER ST2P L108202000220S
CP505 nsp CN.WAFER 7P L101100040710S
CP506 nsp CN.WAFER 14P L101100041410S
CP508 nsp CN.WAFER 4P L101200100410S
CP509 nsp CN.WAFER 3P L101200100310S
CP510 nsp CN.WAFER 7P CN.WAFER 10P L101100041010S
CP511 nsp CN.WAFER 9P L101200100910S
CP512 nsp CN.WAFER 4P ANGLE L102526800400S
CP513 nsp CN.WAFER 3P ANGLE L102526803010S
CP514 nsp CN.WAFER 15P L101200101510S
CP704 nsp CN.WAFER 15P L101100041510S
CP705 nsp CN.WAFER 9P L101100040910S
CP2005,2006 nsp CN.WAFER 7P CN.WAFER 10P L101100041010S
z F501 00D9630236106 FUSE T8A /250V E3 N751228001110S
z F501 00D9630237600 FUSE T4A /250 E2, EA N751224001110S
z F501 00D9600194906 FUSE 125V JP G650802121070S
F501A nsp HOLDER,FUSE CLIP G645000050010S
F501B nsp HOLDER,FUSE CLIP G645000050010S
z F503 00D9630236106 FUSE T8A /250V E3 N751228001110S
z F503 00D9630104704 FUSE T2.5A /250V E2 N751222501110S
z F503 00D9600194906 FUSE 125V JP G650802121070S
F503A nsp HOLDER,FUSE CLIP AVR1909, 789E3, AVC1909 G645000050010S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1909 Specifications

General

Speakers connectivity type	-
HDMI version	1.3a
Product color	Black
x.v.Color support	Yes
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	3
Number of HDMI outputs	1
Ethernet LAN	No
