Denon AVR-1909 Service Manual

108
AVR-1909/789, AVC-1909
F503B nsp HOLDER,FUSE CLIP AVR1909, 789E3, AVC1909 G645000050010S
z F511 00D9630104801 FUSE T3.15A /250V N751223151110S
F511A1 nsp HOLDER,FUSE CLIP G645000050010S
F511B1 nsp HOLDER,FUSE CLIP G645000050010S
z F512 00D9630104801 FUSE T3.15A /250V N751223151110S
F512A1 nsp HOLDER,FUSE CLIP G645000050010S
F512B1 nsp HOLDER,FUSE CLIP G645000050010S
GND501 nsp TERMINAL EARTH 3790040886000S
z JACK501 00D9600181508 SOCKET,POWER RECEPTA E3 G435204004010S
z JACK501 963641000810S SOCKET,POWER RECEPTA E2 G435302D00600S
z JACK501 00D9600181508 SOCKET,POWER RECEPTA JP G435204004010S
RLY501 963682000640S RELAY HL3-1A-6SH G680060102020S
z SUB501 00D9630387602 POWER TRANS E3 8200280150401S
z SUB501 00D9630382801 POWER TRANS E2, EA 8200280150410S
z SUB501 00D9630382908 POWER TRANS JP 8200280150430S
nsp LABEL FUSE E2 5507000002230S
nsp LABEL FUSE JP 5507000002240S
nsp LABEL FUSE EA 5507000001960S
nsp HEAT SINK 2120044338010S
nsp HEAT SINK 2120210958040S
nsp SCREW(3X8 B-TYPE ZNY/BH) B020030081B10S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1909 Specifications

General

Speakers connectivity type	-
HDMI version	1.3a
Product color	Black
x.v.Color support	Yes
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	90 W
HDMI in	3
Number of HDMI outputs	1
Ethernet LAN	No
