Denon AVR-2309 User Manual

Carefully check the left (L) and right (R) channels and the inputs and outputs, and be sure to interconnect
correctly.
Connecting the Recording Components
R
L
R
L
R
L
R
L
015*$"-
47*%&0
47*%&0
*/
3-
3-
*/*/
065
"6%*0 7*%&0
"6%*07*%&0
065
"6%*0
"6%*0 7*%&0
7*%&0
065
*/
015*$"-
065
065
)%.*
Video Cassette Recorder
Select the terminal to use and connect the device.
Video cassette recorder
• When recording via the AVR-2309, the playback device’s cable must be of the same type as the cable
used to connect the AVR-2309’s VCR OUT connector.
Example: TV IN → S-Video cable : VCR OUT → S-Video cable
TV IN → Video cable : VCR OUT → Video cable
• When using a component video cable for the video connection, make the settings at menu “Input Setup”
– “Assign” – “Component In” (vpage 35).
NOTE
Do not connect the output of the component connected to the AVR-2309’s OPTICAL2 output connector to
any input connector other than OPTICAL2.
R
L
R
L
R
L
R
L
3
-
3
-
*/
"6%*0
"6%*0
065
"6%*0
CD Recorder / MD Recorder / Tape Deck
Make analog connections if you wish to record analog audio signals, or digital connections if you wish to
record digital audio signals, depending on the types of connectors on the components being used.
CD recorder /
MD recorder /
Tape deck
R
L
R
L
47*%&0
065
"6%*0
7*%&0
7*%&0
065
065
015*$"-
"6%*0
3
-
065
Video Camera / Game Console
Video camera /
Game console
Carefully check the left (L) and right (R) channels and the inputs and outputs, and be sure to interconnect
correctly.
Connections to Other Devices

Getting Started Connections Setup Playback Remote Control Multi-zone Information Troubleshooting
ENGLISH
Specifications

Denon AVR-2309 Specifications

General

Number of Channels	7.1
HDMI Inputs	4
HDMI Outputs	1
Dolby Technologies	Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Pro Logic IIx
Auto Calibration	Audyssey MultEQ
Component Video Inputs	3
Analog Audio Inputs	7
Response Bandwidth	10 - 100000 Hz
Signal-To-Noise Ratio	100 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Presets	56
HDMI Switching	Yes
Surround Sound Effects	Yes
Digital Sound Processor (DSP)	Yes
DSP Preset Qty	7
HDMI Pass-Through	Yes
Frequency Response	10 - 100000 Hz
DTS Technologies	DTS-HD Master Audio
Digital Audio Inputs	2 Coaxial
Audio D/A Converter	192kHz/24-bit
Amplifier Output Details	100 Watt - 8 Ohm - 20 - 20000 Hz - THD 0.08% - 7 channel(s)
